Cnc Mill 4axis Wantai Nema 23 Stepper Motor 425oz-in,57bygh115-003b&driver Kit

US $590

Changzhou ,Jiangsu, China
Jan 29th

Open on mobile:
QR code

This item includes: 4 PCS Wantai Nema 23 Stepper Motor 57BYGH115-003B dual shaft with 425oz-in holding torque,3A,4-Leads,2 Phase , high Holding torque ! Very Popular in CNC ,Engrave,Mill ... ... 4 PCS Wantai Stepper Driver with 4.2A DQ542MA digital series replacing M542, 1 PC Power Supply for 350W,24VDC,14.58A (Can Also match with 2PCS 350W 36V,9.73A,if need ,pls contact with me ,Thank you ) 1 PC DB25 Breakout Board & 1 Cable for free offering This item can work with Mach3 Software ! Wish you have a nice shopping here ! :D http://www.wantmotor.com 1, Stepper Motor Technical Specifications Part No.: WT57STH115-0304B(57BYGH115-003B) Frame Size: NEMA23 Step Angle: 1.8 degree Voltage: 6.3VDC Current: 3 A/phase Resistance: 2.1Ohm/phase Inductance: 9mH/phase Holding torque: 30Kg-cm 425oz-in Rotor inertia: 810 g-cm2 Detent torque: 0.89 kg-cm Number of wire leads: 4 Weight: 1.55KG Length: 115mm 2, Stepper Motor Driver with 4.2A Current, 128 Microstep DQ542MA is a type of two-phase hybrid stepping motor driver, The drive voltage of which is from 18VDC to 50VDC. It is designed for use with 2-phase hybrid stepper motor of all kinds with 42mm to 86mm outside diameter and less than 4.0A phase current. This circuit that it adopts is similar to the circuit of servo control which enables the motor run smoothly almost without noise and vibration. Hording torque when DQ542MA run under high speed is also significantly higher than the other two-phase driver, what’s more, the positioning accuracy is also higher. It is widely used in middle and big size numerical control devices such as curving machine, CNC machine, Computer embroider machine, packing machines and so on. Features: l High performance, low price l Average current control, 2-phase sinusoidal output current drive l Supply voltage from 18VDC to 50VDC l Opto-isolated signal I/O l Overvoltage, under voltage, overcorrect, phase short circuit protection l 15 channels subdivision and automatic idle-current reduction l 8 channels output phase current setting l Offline command input terminal l Motor torque is related with speed, but not related with step/revolution l High start speed l High hording torque under high speed Electrical specification: Input voltage 18-50VDC Input current

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Wantai Motor
Country of Manufacture	China
Model	57BYGH115-003B
