Cnc One Single Axis Tb6560 3.5a Two Phase Hybrid Stepper Motor Driver Controller

US $310

Guangzhou, China
Jan 29th

Open on mobile:
QR code

CNC One Single Axis TB6560 3.5A Two Phase Hybrid Stepper Motor Driver Controller #A980A Click To Enlarge Top Descriptions Overview HY-DIV168N-3.5A subdivision-type two-phase hybrid stepping motor drive using DC 12 ~ 36V power supply, suitable for drive Two-phase hybrid stepping motor dynamic voltage 12 to 36V, the current is less than 3.5A outer diameter of 35 to 86 mm. This drive using the drive's current loop subdivision control, the motor torque ripple is very small, low-speed running is very smooth, almost no vibration and noise. High-speed torque is much higher than other two-phase drive, high positioning accuracy. Widely used in the engraving machine, CNC machine tools, packaging machinery and other high resolution requirements on the device. The main features 1 average current control, two-phase sinusoidal current drive output 2 DC 12 ~ 36V power supply, the internal integration of 12V and 5V regulator 3 optically isolated signal input / output 4, overvoltage, undervoltage, overcurrent, and white short-circuit protection 5 4 file segmentation and automatic half-streaming capabilities up to 16 segments 4 file output phase current settings 7 high starting speed 8 high-speed torque ?, the electrical parameters Input voltage DC 12 ~ 36V input The input current of 1 to 4 amps, select the drive a stepper motor. Output current of 0.5A ~ 3.5A Temperature Operating Temperature -10 to 45 ℃; Storage temperature -40 ℃ to 70 ℃ Humidity not condensing, not drops Gas prohibit combustible gas and conductive dust Weight 200 grams ??Control signal interface Figure 1 is a wiring schematic of the drive 1, the definition of control signals PUL +: step pulse signal is input side or the positive pulse signal input positive terminal PUL-: the negative input of the negative input pulse signal or a positive pulse signal DIR +: stepping direction signal input to the positive terminal or negative pulse signal input to the positive terminal DIR -: stepping direction signal input of the negative side or reverse step pulse signal input negative terminal EN +: offline can reset signal input side is EN-: offline can reset signal input negative terminal Offline enable signal is active, reset drive failure to prohibit any pulse, the output of the drive Power component is turned off, the motor holding torque. 2?Control signal connections PC control signal can be high, also can be low effective. When active high, the control signal The negative side together as a signal to active low, positive side of all control signals together as a signal common. Click here to download the manual ! Package list: 1 * One Axis TB6560 3.5A Stepper Motor Driver NOTE We try our best to make every transaction perfectly,just for winning your Five-Star rating. If you have any dissatisfaction, please contact us, we will give you the most satisfactory results. PLEASE don't leave a neutral or negative easily.PLEASE don't open any paypal or eBay cases without communication. If not, we will refuse to do busniess with you for next time. Shipping Item will be shipped within 24 hours on payment received from China using Airmail. Only shipped to buyer's PayPal address, please confirm with your PayPal address before you bid. Delivery time depends on destination and other factors, it may takes up to 30 business days.We are not responsible for any custom duty or import tax, you need to pay for the return shipping fee if you don't custom clearance on time. Optionally, Express Shipments with tracking service via EMS/DHL/UPS with a quoted delivery time of 5 to 7 business days is also available . Here is the estimated time for your reference only: Country Delivery Time Working Days (not including holiday) 5-7 8-10 11-14 15-19 20-25 >30 Working Days + Saturday + Sunday 5-9 10-14 15-20 21-25 26-35 >40 United States Rate (item arrived) 9% 50% 21% 13% 7% Refund or Resend United Kingdom Rate (item arrived) 10% 62% 20% 3.5% 4.5% Refund or Resend Australia Rate (item arrived) 23% 50% 13% 8% 6% Refund or Resend Europe (Exclude Russia ) Rate (item arrived) 2.5% 22% 42% 24% 9.5% Refund or Resend Asia Rate (item arrived) 8% 45% 35% 10% 2% Refund or Resend Canada Rate (item arrived) 0.0% 44% 35% 18% 3% Refund or Resend Russia Braizl South America Rate (item arrived) 0% 0% 2% 8% 80% Refund or Resend Return It is buyer's responsibility to contact us within 30 calendar days of receiving a defective product. Otherwise, no replacement or refund will be made. All items MUST be returned in their original condition. Buyer is responsible for shipping and proof of delivery on all returns. Payment We only accept PayPal. Payment must be made within 7 calendar days of the auction end time. Non-Paying bidders will be reported. We reserve the right to cancel your order if the payment is not made within 8 calendar days of checkout. Engineered for professional eBay sellers! On Dec-16-14 at 10:30:47 PST, seller added the following information:
