Cnc Rotary Axis 4th Axis 3 Jaw Router Rotational Chuck 100mm For Cnc Machine

US $2900

shenzhen,Guangdong, China
Nov 20th

Open on mobile:
QR code

Store Home New Arrivals On Sale Shipping Payment Feedback Contact Store Categories Stepper Motor Drive System AC Servo Motor Drive System HMI Touch Screen Variable Frequency Drive Spindle Motor PLC Encoder Automation Switches Transformer&Power Supply Other Store Newsletter Add my Store to your Favorites and receive my email newsletters about new items and special promotions! General Interest Why Buy From us CNC Rotary Axis 4th Axis 3 Jaw Router Rotational Chuck 100mm for CNC Machine Items Description 1. Application Fields (1) CNC 4th axis ( A aixs, Rotary axis ) with chuck for cnc router cnc miiling machine (2) hollow shaft Rotary axis 3 Jaw 100mm chuck CNC 4th Axis CNC dividing head for cnc router (3) Rotation 6:1 A axis for Mini CNC router/engraver woodworking engraving machine (4) Specifications Model Number K11-100 Chuck K11 100MM 3-jaw chuck Height 115MM Angle 0.3 degrees / step Speed reducing ratio 6:1 (Synchronous belt) Synchronous belt 3mm(tooth width) 336mm(belt length) width 15mm Stepper motor Two phase 57 NEMA23 stepper motor 2. 4th axis pulse equivalent SETUP: Mach3 system settings number of pulses of 1 Degree (number of pulses of Motor/lap* micro-stepping levels of Drive * reduction ratio)/360 degree such as: Two phase Nema23 Motor micro-stepping levels:16 reduction ratio:50 (200×16×50)÷360=444.44444444 control card system settings The angle of one-pulse 360 degree/( number of pulses of Motor/lap* micro-stepping levels of Drive * reduction ratio) such as: Two phase Nema23 Motor micro-stepping levels:16 reduction ratio:50 360÷(200×16×50)=0.00225 The replace algorithm of X or Y Axis: perimeter/( number of pulses of Motor/lap* micro-stepping levels of Drive * reduction ratio) Shipping Payment Terms of Sale About us Contact us 1.Orders will be shipped out within 5 working days once payment received. Please make sure the phone number is valid. 2.We Will ship by DHL, FedEx, UPS, EMS( we will choose the best way to ship the items ASAP). You will be updated the tracking number via ebay and email. Generally, it takes 3-7 delivery days to your shipping address. 3.Kindly please note the tax fee and clearance fee are not included in the item price. You have to take the responsibility for the tax and clearance fee. Only Paypal is accepted. Normally we provide 12 months warranty, some regular items even up to 24 months.Please see the details above. Products are tested before shipping ,and we guarantee our products are in good working condition. If the product you received is defective caused by shipping, please contact us before you return to us. We will RESEND the good product to you ASAP or will full refund you the payment. FastToBuy.Com is a worldwide industrial products online store of over million configurable and standard components. We are a leading provider for industrial automation control, CNC machine and electrical equipment. Each product, in which FastToBuy sales online, is subject to a 100% quality control. we have enough stock, if you want to buy more, please feel free to contact us,we will add the quantity. please contact us via ebay or paypal Note:If you have any question,please feel free to contact us.our service team will reply you as soon as possible.Due to the time zone difference,we may not be able to reply you immediately,Please allow us to respond you in 24 business hours. Other ways: Grace: ebay@fasttobuy.com +86-755-82546545 Grace: Service@fasttobuy.com +86-755-82550561 Copyright @ fasttobuy 2016 rights reserved. On Sep-12-16 at 20:42:20 PDT, seller added the following information:On Nov-07-16 at 22:46:38 PST, seller added the following information:On Nov-07-16 at 22:46:42 PST, seller added the following information:
