Cnc Router Machine 4040-xe, 300w Spindle 3-axis Engraving Milling Machine For Wo

US $1,399.00

Phoenix, Arizona, United States
Aug 8th

Open on mobile:
QR code

CNC Router Machine 4040-XE, 300W Spindle 3-Axis Engraving Milling Machine for Wood Metal Acrylic MDF Nylon Carving Cutting Arts and Crafts DIY Design Product Details Product Specifications Active Working Area 15.75 x 15.75 x 2.16 inch (400 x 400 x 55mm) Spindle Power 300W Stepper Motor NEMA 23 Accuracy 0.1mm Max. Moving Speed 2000mm/min Input Power Supply 110V/10A Control Method Computer/Controller offline control Firmware GRBL 1.1h Support Software Compatible with Grbl-control software Support OS Windows XP/7/8/10, Linux, Mac OS Machine Size 29.92 x 24.4 x 14.17 inch (760 x 620 x 360mm) Support Add-ons 5W/15W/20W power module; DWP611 router (need a different z clamp). (Add-ons are NOT included) Main Features 300W Powerful Spindle 4040-XE CNC Router uses 300W spindle and NEMA23 stepper motors, which are more powerful and efficient. Large Active Working Area The 4040-XE CNC router has engravable area of 15.75”x15.75”x2.56” (400x400x65mm), which can handle both small and large material. Safe Integrated Controller Box Control board, power supply, emergency stop, and wires are integrated into a newly design box, which is simple for operation, easy to clean and safe. Using Tips Select control mode before using: Computer or Controller. After power on the machine, first click "unlock", and then to start to move and engrave. Product Details Switchable to Power Module The machine comes with a 300W spindle. Spindle is switchable to 15W power module max. (Power module is NOT included) Aviation Plug Aviation plugs are safe and easy for maintenance. Cable Management Wires are bundled into drag chain neatly for easy management. Easy Assembly Step 1 Install wasteboard and dust baffles Step 2 Install gantry Step 3 Install Z-axis and spindle Step 4 Wiring 4040-XE 3018-SE V2 Masuter Active Working Area 15.75” x 15.75” x 2.16” 11"x 6.18"x 1.3" 15.75” x 14.96” x 2.16” Spindle Power 300W 60W 60W Emergency-Stop Z-Probe Limit switches Enclosure X X Stepper Motor NEMA23 NEMA17 NEMA17 Z-axis Clamp Accommodate 5W/15W/20W module Accommodate 300W spindle and 5W/15W/20W module Accommodate 300W spindle and 5W/15W/20W module Shortcut Buttons X X Home shortcut button Package List 1x 4040-XE CNC router (half-assembled) 1x Wastboard 1x Controller 2x Set of engraving bits (10pcs/set) 1x USB cable 1x Power cord 1x Box of screws and tools 1x User manual 4040XE CNC Router uses 300W spindle and NEMA23 stepper motors which are more powerful and efficient Max moving speed is 2000mmmin and spindle speed range is 010000 Control board power supply emergency stop and wires are integrated into a newly design box which is simple for operation easy to clean and safe The controller has a 35 touchscreen LCD which also functions as an offline controller The input voltage is 110V Its capable to engrave cut and drill many different kinds of material such as wood metal MDF acrylic foam resin nylon carbon fiber PCB and etc Its great for home use and business Large engravable area of 1575x1575x256 400x400x65mm Its capable to handle both small and large material The CNC machine is based on GRBL it is compatible with GRBLcontrol software Easy assembly Main parts are preassembled it only takes 1530mins to fully assembly Wires are labeled clearly for fast connection and bundled into drag chain for easy management width: x height: 27.95 x length: 10.24 x weight: 0 Payment Details We accept payments through PayPal, contact us to check the availability of other payment methods Shipping Details Items located in our US warehouse will be Shipped FREE to all addresses other than APO/PO boxes in the lower 48 states via USPS or UPS (depending on location and package weight) Unless stated otherwise, all orders will ship within 1-10 days of your payment being processed. Please note that import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Check with your country's customs office to determine what these additional costs will be prior to bidding/buying, WE DO NOT COMPETE WITH BIG STORES Thank you. Delivery & Return Policy Details Return shipping is the buyer's responsibility unless the return is a result of our mistake. We will pay for shipping replacement back to you if an exchange is requested

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	4040-XE
Part Number	4040-XE
UPC	Does not apply
Package Dimensions	33.46 x 27.95 x 10.24 inches
ISBN	Does not apply
Color	Black
EAN	Does not apply
Voltage	110 Volts
Brand	FoxAlien
Installation Method	Screw-In
Control	CNC
Plug Format	B - US style with ground plug.
Machine Type	3 Axis Router Machine
Special Features	Easy to Install
Power Source	Ac/dc
Included Components	1/8-Inch Collet
Model Year	Unknown
Batteries Required?	No
Manufacturer	FoxAlien
