Cnc Router Milling Machine Diy Plans

US $50.00

Gorenja vas, default, Slovenia
Feb 14th

Open on mobile:
QR code

4 axis professionall CNC router ZEOS 170 work area: 1700 x 1000 x 450 mm including plans for rotational servo axis blueprints, 2D dxf files for laser cutting sheetmetal, complete 3D assembley, bill of material, list of parts & supliers links Build your own high quality CNC router for milling wood, plastic and aluminium. Here we offer plans for allready built and tested CNCmachine. FEATURES: Stable and rigid steel construction, designed for high speed milling Powerfull servo motors, acceleration 1g, feedrate 15-35 m/min Zero backlash ballscrew on all axis professional linear guides on all axes 4,5 kW, 2400 rpm, iso30 ATC professional spindle motor included in price: 3D assembly model, 2D documentation, bill of material, parts codes and supliers links after payment all files will be sent wia weetransfer or dropbox SPECIFICATIONS: ZEOS 1700 work area: 1700 x 1000 x 450 mm additional rotational axis axes repeatability: 0.01 mm axes resolution: 0.005 mm X axis servo: 1000W Y,Z axis servo: 750W Steel base: 150x150x5 mm welded square tubing Y,Z axis: 5mm welded sheetmetal NC indexing table IIID 175 resolution: 0.0144° backlash: 0.02° max rpm: 20 min-1 holding torque: 175 Nm output bearings rating: C0 = 33500 N output bearings permissible tilting moment: 3350 Nm reducer maximum torque: 400 Nm drive motor: stepper motor with encoder and controller (closed loop ) We reccomend instalation of following CNC controllers: Mach 3: wery good price/performance, easy to install. Can achiewe 15m/min feedrate, 0.005mm resolution. Can not support high speed milling Softservo: versatile and powerfull CNC controllers, easy to install. Enables HSC(high speed cutting) 3D-DLAC (Advanced 3D Contour Control for High-Speed Machining) SIEMNS 820D, HEIDENHAIN 340: High end CNC controllers

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

Country/Region of Manufacture

Slovenia
