Cnc Router Rotational Axis Engraving Machine 4th Axis With Stepper Motor Jawchuk

US $228.00

Changzhou,Jiangsu, China
Jan 30th

Open on mobile:
QR code

Package include: 1 x set of 4th axis 3:1 (K11-100mm 3-jaw chuck) Engraving machine fourth axis (A axis, Rotational Axis, CNC dividing head) with K11-100mm three jaw chuck Nema34 stepper motor (without return difference) Chuck type: K11 100mm three jaw centering chuck Clamping range: Positive claw (2~30mm), anti claw (30~80mm) Center height: 65mm Output shaft : 20mm Angle: 0.6°/ step Reducing ratio: 3:1 Stepper motor: Nema34 86mm 4.5A 2-phase 4 wire Motor shaft :14mm Accessories: Set of Anti-claw and wrenches Size: 210x210x115mm Weight: 9 kg The fourth axis parameter settings: Mach3 system settings: the pulses required for 1° (Motor 1 lap pulses x Driver fine fraction x Reduction ratio) ? 360° For example: 57mm 2- phase stepper motor, fine fraction of 16, reduction ratio 100:1 (200 x 16 x 100) / 360=888.88888888) Weihong system settings: 1 pulse along the angle 360°/(Motor 1 lap pulses x Driver fine fraction x Reduction ratio) For example: 57mm 2- phase stepper motor, fine fraction of 16, reduction ratio 100:1 360 / (200 x 16 x 100) =0.001125 Shipping Please open the package and check if there are some damages before sign, if there are some damages , please do not sign and contact us immediately We ship to worldwidebut If your country’s custom is strict, please contact us before you bid to check detail and confirmed. Payment We accept paypal payment,all Paypal must be confirmed(shipping and billing address must match and correct) Payment must be made within 48hours of the auction end time Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer responsibility. Problem&Feedback Please give us the opportunityto resolve any problem when you have,we concern your problem and we will try our best to resolve it. We are a new member in ebay now,and need understand both of sides Pls email us before you want to leave any negative feedback Refund When you have the parcel,and not satisfied the goods or it is other problem like as broken,pls tell us the detail reason and provide the photos Any reason required for all refund. Item must be in it's original condition and no physical damage. Buyer responsible for all shipping cost . Contact us Welcome worldwide customer inquire and questions,we will try to do our best to feedback customer’s email within 1-2 business days,if not pls check the mail box again Customer’s satisfaction is very important to us.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	China
Output shaft	20mm
is_customized	Yes
Angle	0.6°/ step
Brand Name	RATTM MOTOR
Reducing ratio	3:1
Number of Jaws	3
Stepper motor	Nema34 4.5A 2-phase 4 wire
Power	Manual
Clamping range	Positive claw (2~30mm), anti claw (30~80mm)
Model Number	K11-100mm 3-jaw
Motor shaft	14mm
Chuck type	K11-100mm 3-jaw
Net Weight	9kg
Center height	65mm
