Cnc Usb Pendant Handwheel Shuttleru_stm32 With Touch Screen 2.8" Lcd For Mach3

US $280.00

Taganrog, Russian Federation
Jan 29th

Open on mobile:
QR code

USB Pendant ShuttleRU_STM32 with a Touch Screen 2.8" display for Mach3. Description: To help make running your CNC machine more convenient and improve you efficiency I have created the ShuttleRU_STM32. Installation is quick and simple with it’s USB interface and custom Mach3 plugin. The ShuttleRU_STM32 is built to be tough. The case, buttons and both the inner jog wheels and the outer shuttle ring are all made of aluminum. 17 buttons, one used for the Shift function, which allows at total of up to 32 functions to be defined to make using your machine easier. The outer shuttle ring snaps to a center off position and can be twisted in either direction to control the direction of movement of the currently selected axis. The shuttle can be twisted about 75 degrees in either direction the more twist the faster the current axis moves in the twisted direction. The Inner Jog wheel acts as a precision MPG allowing you to precisely move to a specific location. The combination enables you to quickly move over long distances and easily switch to precise control when you are near the exact position you want. This is all done effortlessly and with much less wear and tear than using an MPG alone. Installation is quick and simple with it’s USB interface just plug it into the PC’s USB port and it will install the pendant as a new HID device. Then put the custom plugin DLL file into your mach3 plugins folder usually located at “your install directory\Mach3\plugins. If the CNC machine has an Power failure the pendant can remember the line number that mach was executing before the failure. This way later you can continue from this line. The screen layout can be customized by the user in a specially written program called ScreenDesigner it allows you to build multiple screen layouts and create bargraphs and DROs, LEDs where ever you want on the screen. The program (similar to Screen4 Mach3) is easy to use and has many options for output elements. The elements are arranged on the screen by dragging and dropping. And a grid is present to ease the aligning of elements on the screen. The grid also aids in placing elements using coordinates and helps with the use of scales. The generated files are loaded into the memory card of the pendant using the SD card reader. You can create any number of screens and switch between them by touching the screen using gestures of up and down movements on the screen. . This can be done while using the pendant to control your cnc machine. Each screen can display any number of items that can be selected from a list of 20 user defined Items. All elements have an order numbers, and can be further configured in the plugin. Here is a working image of the ShuttleRU_STM32: The Pendent uses a 32-bit ARM™ controller a CortexTM - M3 STM32F103** with built-in USB interface, creating a simple interface and improve performance. Package List: * ShuttleRU_STM32 pendant * MicroSD Memory Card Payment: I accept Paypal only. Please pay within 2 days after the auction ended. I am not responsible for any custom duty or import tax. You can pay via Paypal anytime, and your package will be sent out within 3 days (except weekend and holidays) upon receiving the payment. Serious Buyer Only! Please place bid only if you agree with all the terms. Shipping: 1. Item will be sent out within 3 days(except weekend and holidays) after I receive the payment. The item is shipped by Russian Post air mail with tracking number. 2. It is estimated that package will arrive in 20-35 working days. (holidays and weekends are not included) to most countries! If you donot get the items after 30 working days please email me. 3. I is not responsible for any custom duty or import thanks. 4. I am ship the item to the address listed in your paypal payment only. Please make sure your shipping address is correct. 5. If you have any request (e.g. change address), please put a note on paypal. Have a nice shopping!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Homemade
MPN	ShuttleRU_STM32 pendant
Model	ShuttleRU_STM32
Country of Manufacture	Russian Federation
