Cnc Woodworking Machine -flat Table Machine (w/atc/boring)

US $11,900.00

Orlando, Florida, United States
Aug 16th

Open on mobile:
QR code

BUSELLATOJET 3006RT FLAT TABLE MACHINE (W/ATC/BORING) Dimensions: 168" L x 96" W x 84" H Weight: 8,500 Lbs Specifications: 4' x 10' "Matrix" grid phenolic surface table for"Nested Based Manufacturing". Working Cap: "X" Axis is 121.2" (3,080 mm), "Y"axis is 49.2" (1,250 mm), "Z" axis stroke is 8.1" (205 mm);max. panel thickness is 5.9" (140 mm); Positioning Speed: "X" axis is 246 FPM (75 MPM), "Y" axisis 197 FPM (60 MPM), "Z" axis is 50 FPM (15 MPM). Work Table: (2) independent working areas with locating stop pins on thefront & rear - LH & RH sides for positioning of parts on the worktable;prepared for (optional) elevated pods that allow profile & horizontalmachining. Boring Unit: (1) 4 HP (3 kW) - 4,000 RPM motor; (16) Independent verticalboring spindles with (8) spindles in "X" axis & (8) spindles in"Y" axis, (4) horizontal spindles with (1+1) spindle in "X"axis & (1+1) in "Y" axis; 120 mm "X" axis groving saw; Boring block is inverter controlled with variable spindlespeed up to 4,000 RPM. Machining: (1) 14 HP (10 kW) Liquid cooled vertical electro-spindlerouter with HSK-F63 adaptor, inverter driven 1,000 - 24,000 RPM with max.torque from 12,000 - 24,000 RPM; (1) 10-position "Ride Along" automatic rotary toolchanger for "on-the-fly" ATC. Operator & Machine Control: "PC" Front-End with "GENESIS" + Windows'95, '98 & NT operating system; 32-bit Pentium - 400 MHz processor; 4 GBhard drive, 15" Color monitor, international keyboard, soft touchkeypad & industrial mouse, RS-232 serial port and (1) 1.44 MB floppy diskdrive. All built-in to a 1,500 W air conditioner for constanttemperature & dust-free environment. GENESIS operating system has real-time multitask processing;programs can be transferred via diskette or downloaded by wire is possible Complete With: (1) 40 HP Dekker V-max vacuum pump; automatic"forced" lubrication system for guides & ball screw; emergencystop rope & pressure sensitive safety mats that will instantly placemachine in "pause cycle" when stepped on; sound absorbing protectivehead enclosure with debris curtain around bottom edge.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Busellato
MPN	BUSELLATO JET 3006RT FLAT TABLE MACHINE (W/ATC/BORING)
Model Year	2002
Country/Region of Manufacture	Italy
Custom Bundle	Yes
