Cnc Xpro V4 Controller Spark Concepts

US $150.00

Cupertino, California, United States
Jul 3rd

Open on mobile:
QR code

The CNC xPRO V4 is the culmination of over 5 years of CNC xPRO development. This controller brings a perfect union of easy setup and use with performance and reliability. The V4 board features isolated digital and analog power buses to greatly reduced noise and false triggers. Introduced with the V4 is our new DriverMinder logic - the V4 constantly monitors the status of each motor driver looking for any fault. Should a fault occur, your selected action will be taken, options are: Pause - will initiate a system pause allowing you to safely troubleshoot and potentially save your workpiece Stop - emergency abort, system stop immediately and reboots Play - continue on as if nothing happened (AKA ignore fault). What's new for V4: TL/DR - all of it! Less than 5-minute install with the use of plug and play motors headers, limit switches and power supplies 4-layer design featuring completely isolated motor and logic power buses All smd parts moved to back of board to protect again debris and short Integrated #4-40 standoff for easy mounting and short protection Three ways to power - Laptop PSU (2.5x5.5mm plug), a 2 wire power supply, or ATX computer power supply Selectable spindle output voltage range: 0-5V or 0-10V for full compatibility with spindles, VFDs, Lasers and more Coolant output is now an open drain (directly sink up to 3A or use to control external relays) Screw terminal hookup for external Step/Dir drivers makes beefing up easy Extremely robust power management for overvoltage/reverse voltage protection including replaceable mini blade fuses Motor driver step and fault LEDs for easier troubleshooting Enhanced silkscreen with more pictures and less labels Compatible with Openbuilds XTension wiring system for even easier setup! DIP SWITCHES = NO MORE SOLDER JUMPERS - want to change decay mode -> slide the switch, want to clone Z motion instead of Y -> slide the switch Specs: Pre-loaded with latest stable version of GRBL Compatible with ESTLcam Capable of powering from ATX PSU, edicated 12V/24V two wire power supply, or a laptop power supply Drive 4 motors with DRV8825 Stepper Drivers - 2.5A (peak) with 1.75A (RMS) with up to 1/32 microstepping 1 Driver capable of cloning X,Y, or Z Hardware support for both USB and Wireless Operation (XBee, WiFly, or Bluelink)* Emergency Stop to cut all motor power (with optional override) 12V and 5V** outputs for powering peripherals (fans, pumps, vacuums) Quickly connect to Stepper Motors and limit switches with 3.5mm screw terminals and/or 4-pin 0.1" (2.54mm) headers Expansion port for coming upgrades (Illuminated button pendant, jog control, and headless sender) *For CNC applications we recommend Bluelink Use the CNC xPro to drive: 3 Axis CNC Mill With Dual Drive Motors Laser Cutter With XY, and Z motion Plasma Cutter Pick and Place for SMD components Or wireless robotics (would love to see this used on a wireless quadruped) Software: The CNC xPRO is designed to run the opensource gcode interpreter GRBL, ESTLcam control software, or can be programmed with Arduino or AVR studio. The xPRO comes pre-flashed with GRBL so all you need to do is wire up your motors! From the computer side we have found that CNCjs Desktop is amazing and packed with great features! (open source / free download). For designing parts here at Spark Concepts we use the following stacks: For mechanical parts (think gantry plates, mounts, boxes, etc): Fusion 360 (both CAD design and CAM, includes GRBL postprocesser by default) (free for hobbyists) CNCjs (send and monitor the cut file to the xPRO) (free/opensource) For artwork (think signs, drawings, plaques, awards, etc): Vetric Vcarve or Aspire depending on design (drawing and CAM, includes GRBL postprocessor) (paid) CNCjs (send and monitor the cut files to the xPRO) (free/opensource)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	CNC xPRO V4
Brand	SPARK CONCEPTS
Number Of Axes	3
Run Method	Bipolar
MPN	Does Not Apply
