COILTRONICS Incorporated ECONO-PAC Surface Mount Inductor Design Kit. >I2, US $630 – Picture 0
COILTRONICS Incorporated ECONO-PAC Surface Mount Inductor Design Kit. >I2, US $630 – Picture 0

Coiltronics Incorporated Econo-pac Surface Mount Inductor Design Kit. >i2

US $630

  • Cedar Rapids, Iowa, United States
  • Jun 24th
Open on mobile:
QR code
Item recovered locally and sold AS IS. This auction is for a COILTRONICS Incorporated ECONO-PAC Surface Mount Inductor Design Kit. This kit came in from a production facility along with other nice items. This kit is new, but not complete. It looks like each compartment is suppose to have 2 inductors in it, but there are 3 compartments that only have one inductor in it. It is the CTX5-1P, CTX10-1P, and CTX8-3P compartments that only have one inductor. Fortunately, there is a sealed package of 25 CTZX10-1P that came with it, so there is now more than two of those! The inside cover of this kit shows the PARTS LOCATOR, which is a map of what is in each compartment. To the right of this it shows the data of each inductor, whether installed parallel or series, such as Open Circuit Inductance uH +/- 20%, Full Load Inductance uH min, Full Load Current Adc and DC Resistance ohms max. At the bottom are charts showing Inductance vs. temperature, inductance vs. current and temperature rise vs. rated current. Nice kit! 118 pieces total if my count is correct. Will start out at 50 cents apiece and see where it goes. Thanks for your time. Buyer pays shipping cost, please see shipping statement before making any payment, thanks! Effective immediately (10/24/13), all foreign winners will have to have item shipped via USPS International Priority Mail due to items being "lost" in shipment and not being able to track if sent via USPS International First Class Mail. Do NOT bid if you do not agree with this policy. Until we can change all listings, you will be charged at the International Priority rate. Thanks.
