Combo Exit And Emergency Light Xcl Series With Battery Back-up - Ul Listed

US $65.95

Miami, Florida, United States
Jan 30th

Open on mobile:
QR code

LED Emergency combination Exit & emergency unit with Battery Backup - UL Listed PRODUCT OVERVIEW The XCL series combination exit & emergency unit features an attractive, contemporary thermoplastic housing design. Ideal for commercial and institutional installations, the XCL series combination unit blends perfectly with current interior decors. The XCL series uses high-output red or green LED technology. Universal mounting on the wall or ceiling allows installation versatility. Emergency lighting heads can be swiveled 360° providing effective and accurate emergency illumination. INTERNAL SPECIFICATIONS SELF-POWERED: standard 120/277VAC input, self-powered versions use sealed nickel-cadmium batteries to provide a minimum 90 minutes of emergency duration. Electronic cut-off circuit prevents over-discharge. EXTERNAL SPECIFICATIONS The XCL series is constructed from durable corrosion and flame resistant thermoplastic. The XCL series comes standard with a mounting canopy, two (2) stencils, one (1) back-plate, remove-able chevrons and all mounting hardware. Side mounted emergency lighting heads rotate 360° providing a new level of adjust-ability. The XCL series comes standard finished in white; optional black finish is available. Remove-able chevron arrows are standard on each fixture. External LED status indicator and test switch are standard. INSTALLATIONThe XCL series combination unit is suitable for surface ceiling, and wall mounting. Suitable for indoor and damp location installations MODERN DESIGN The XCL series combination exit & emergency unit provides an attractive, versatile, space saving and affordable solution. The durable thermoplastic housing is corrosion and flame resistant. The XCL series stencils include removeable chevrons that allow for easy “in the field” installation decisions. The modern and effi-cient design of the XCL series allows for surface ceiling, and wall mounting. Canopy and all installation hardware is included. BATTERY TECHNOLOGY The XCL series is designed with a 6V 4.5Ah maintenance free, sealed lead acid battery that provides a minimum emergency du-ration of 90 minutes. Recharge time of the battery is twenty-four (24) hours. The maximum battery working temperature is 50° C. When the XCL is ordered with the “remote capable” option, a larger 6V 7Ah battery is used. ELECTRICAL SPECIFICATIONS The XCL series is configured with high-output LED lamps. LED version is standard with 120/277VAC input. Emergency light-ing heads come standard configured with 5.4 watt incandescent wedge base lamps. RED LED - 4 Watts GREEN LED - 2 Watts MECHANICAL SPECIFICATIONS The XCL series is constructed of durable corrosion and flame resistant thermoplastic. Field removable directional chevron arrows are standard. The XCL series can be universally mount-ed single or double face. Canopy and mounting hardware are included. High-output LED technology provides energy savings, long life and even illumination levels. Side mounted emergency heads rotate 360°, providing accurate emergency illumination. 120/277VAC input, maintenance free sealed lead acid battery is protected by an electronic cut-off circuit that prevents overdischarge. External test switch and monitor LED are standard. SELF-POWERED VERSION The XCL self-powered series is designed to operate on battery power in the event of a regular / mains power failure. Both the battery and charger are completely contained within the standard enclosure. There are no external components and no alterations made to the external dimensions of the standard sign. The XCL self-powered series utilize a solid state transformer technology that eliminates the possibility of relay failure due to particle build up on the relay. Status is easily determined via an LED that indicates AC-ON. A push button test switch allows maintenance personnel to quickly confirm the operational status of the exit on AC fail. *Shipping is shown only for 48 contiguous United States. It does not include HI, AK, Canada or other countries. Please call 305-687-3330 for a quote

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Beghelli
MPN	EM-XCL
Model	XCL series
