Comefri Fan New, Atli F 15-15 Frwd-curve Housed Centrifugal Fan With Mntg Feet

US $660

Scotch Plains, New Jersey, United States
May 29th

Open on mobile:
QR code

Visit comefriusa ATLI (Double width double inlet forward curve housed fan) with mounting feet. FEATURES: Galvanized FC impeller with tab locked blades. Impeller secured to shaft with precision machined hub with keyway and locking set screw Impellers are statically and dynamically balanced to G=6.3 Galvanized housing with built-in inlet cones Housing spot welded 1. Standard ATLI fans range Comefri's ATLI double inlet forward curved centrifugal fan series covers a size range from 7 to 40. All fans within this range have the following characteristics: • optimally engineered for HVAC applications; • high quality, compact design; • class I and class II versions available (as per AMCA operating limits specification 99-2408-69); • Iow power consumption; high efficiency • quiet operation; • all fans are fully performance tested and certified in Comefri's own state-of-the-art laboratory in accordance with DIN, ISO, BS and AMCA standards. 2. Technical details 2.1. Housing All fan housings from size 7 to 40 are manufactured in galvanized sheet steel (Fig. 1). From sizes 7 to 18, the fan sideplates are spot welded to the scroll housing (Fig. 2). The inlet cones are manufactured in galvanized sheet steel and are part of the housing sideplates. A series of standard holes are located on the sideplates to allow the installation of frames or mounting base. These holes are positioned in such a way that several standard accessories can be attached with the necessary fixing screws. 2.2. Impeller The impeller is manufactured in galvanized sheet steel with tab locked blades, (Fig. 4). All wheels are balanced, both statically and dynamically, to an accuracy grade of G = 6.3 in accordance to DIN ISO 1940-1 and ANSI S2.19 – 1989. All the impellers from size 7-7 to 40-40 are secured to the shaft via a hub. The hub bore is precision machined and incorporates a keyway and locking screw. 2.3. Shafts All shafts are designed with a high safety factor and with the first critical speed well in excess of the maximum fan speed. Made with hardened steel, the shafts are precision ground and polished, and includes keyways for the wheel hub and sheaves. All shafts are coated with a protective paint for added corrosion protection prior to shipping. 2.4. Bearings Bearings mounted in a rubber interliner, which in turn, fits in a sturdy three-arm or four-arm spider bracket (Fig. 5). These bearings are permanently lubricated and sealed for the life time of the fan.
