Commscope 4 Way Power Splitter S-4-cpuse-l-n

US $63

Astoria, New York, United States
Jun 4th

Open on mobile:
QR code

S-4-CPUSE-L-N General Specifications Brand Andrew® Device Type Splitter Interface N Female Color Black Electrical Specifications Operating Frequency Band 698 – 2700 MHz 3rd Order IMD -130 dBc (relative to carrier) 3rd Order IMD Test Method Two +43 dBm carriers Average Power, maximum 80 W Dissipative Loss at Frequency Band 0.6 dB @ 698–2700 MHz Impedance 50 ohm Insertion Loss at Frequency Band 0.6 dB @ 698–2700 MHz Isolation at Frequency Band 18 dB @ 2500–2700 MHz | 18 dB @ 698–800 MHz | 20 dB @ 800–2500 MHz Peak Power, maximum 1 kW Power Rating, combining 0.5 W Power Rating, Splitting 80 W Reflected Power, maximum 5 W Return Loss, minimum 17.7 dB Split Loss 6.0 dB VSWR 1.3:1 Mechanical Specifications Inner Contact Plating Silver Outer Contact Plating Trimetal Environmental Specifications Application Indoor/Outdoor Ingress Protection Test Method IEC 60529:2001, IP65 Operating Temperature -25 °C to +85 °C (-13 °F to +185 °F) Relative Humidity Up to 100% Dimensions Height 22.00 mm | 0.87 in Length 129.00 mm | 5.08 in Width 141.00 mm | 5.55 in Net Weight 600.00 g | 1.32 lb Packed Dimensions Height 40.0 mm | 1.6 in Length 160.0 mm | 6.3 in Width 160.0 mm | 6.3 in Shipping Weight 670.00 g | 1.48 lb Volume 1024.0 cc Regulatory Compliance/CertificationsAgency Classification RoHS 2011/65/EU Compliant by Exemption ISO 9001:2008 Designed, manufactured and/or distributed under this quality management system
