Commscope 5513502 Trunk And Distribution Cable 75 Ohm Coax Qr 715 Jcass Pr2355

US $1,000.00

Pasadena, Texas, United States
Jan 29th

Open on mobile:
QR code

1 (ONE) NEW ROLL 2900 FEET COMMSCOPE QR 715 JCASS PR2355 TRUNK AND DISTRIBUTION CABLE 75 OHM COAXIAL CABLE PART NUMBER 5513502 Optimized For Use In Broad Band Distribution Plants You Are Purchasing 1 (ONE) Spool Of Commscope 5513502 (QR 715 JCASS PR2355) Underground Direct Burial Main Trunk Line. The Spool Is 2900 Feet (884 Meters) This Cable Is New, Unopened, Uncut, Unused, And In Original Factory Packaging Phone: Nehemiah (281) 799-0731 If I Do Not Answer Leave A Message I Will Call Back! Brief Description From The Manufacture Website: 75 Ohm QR® Trunk And Distribution Cable, Dual Black PE Jackets, Flooded And Armored For Underground. QR 715 Is Optimized For Use In Broadband Distribution Plants. Aluminum Strip – Formed And Continuously RF Welded Around A High Compression Microcellular Foam Dielectric Core, Minimizing RF Egress And Ingress And The Rigidity Common In Traditional Coaxial Products. Shield – Fully Bonded To The Dielectric Core, As Is The Copper Clad Aluminum Center Conductor. Polyethylene Jacket – Applied Standard, Which Enhances Cable Reliability And Allows QR’s Unique Connector Technology To Form An Environmental Seal. Shipping Info: This Cable, For Shipping Purposes, With The Pallet, Strapping And Stretch Wrap Is 48” x 48” x 36” With A Shipping Weight Of 1357 Pounds (616 Kg) This Cannot Be Delivered To A Residential Address And Will Require Either A Dock Or Lifting Machine To Unload It. The Cost Of Shipping Will Be Determined By Your Zip Code And Street Address. You May Provide Your Own Shipping. I Will Load It On Your Truck Or Trailer Free Of Charge. My Street Address Is: 5130 W Oak Pasadena TX 77503. Phone: Nehemiah (281) 799-0731 Local Pick Up Is Available And I Will Load It On Your Truck Or Trailer Free Of Charge. My Street Address Is: 5130 W Oak Pasadena TX 77503. Phone: Nehemiah (281) 799-0731 There Is No Return Or Exchange Of This Cable. Ask Any Questions You Have Before You Purchase. Phone: Nehemiah (281) 799-0731 The Information Below Is From The Manufacture Website 5513502/30/N/AQ QR 715 JACASS PR2355 Product Overview: Construction Materials Corrosion Protection Migraheal® Jacket Material PE Armor Material Corrugated chrome plated steel Center Conductor Material Copper-clad aluminum Construction Type Armored | Welded Dielectric Material PE Inner Jacket Material PE Outer Conductor Material Aluminum Dimensions Diameter Over Center Conductor, nominal 4.216 mm | 0.166 in Diameter Over Dielectric, nominal 17.424 mm | 0.686 in Diameter Over Outer Conductor, nominal 18.161 mm | 0.715 in Diameter Over Armor, nominal 21.717 mm | 0.855 in Diameter Over Inner Jacket, nominal 19.939 mm | 0.785 in Diameter Over Jacket, nominal 23.749 mm | 0.935 in Armor Thickness, nominal 0.203 mm | 0.008 in Inner Jacket Thickness, nominal 0.889 mm | 0.035 in Jacket Thickness, nominal 1.0160 mm | 0.0400 in Outer Conductor Thickness, nominal 0.3683 mm | 0.0145 in Cable Length 914 m | 3000 ft Shipping Weight 359.00 lb/kft Electrical Specifications dc Resistance, Inner Conductor, nominal 0.58 ohms/kft dc Resistance, Outer Conductor, nominal 0.42 ohms/kft dc Resistance, Loop, nominal 1.00 ohms/kft dc Resistance Note Nominal values based on a standard condition of 20 °C (68 °F) Capacitance 50.2 pF/m | 15.3 pF/ft Capacitance Tolerance ±1.0 pF/ft Characteristic Impedance 75 ohm Characteristic Impedance Tolerance ±2 ohm Jacket Spark Test Voltage 5000 Vac Nominal Velocity of Propagation (NVP) 88 % Operating Frequency Band 5–1000 MHz Structural Return Loss 30 dB @ 5–1000 MHz Environmental Specifications Environmental Space Buried General Specifications Brand QR® Cable Type 715 series Jacket Color Black Packaging Type Reel Short Description QR 715 JACASS PR2355 Mechanical Specifications Minimum Bend Radius, bonded 190.50 mm | 7.50 in Pulling Tension, maximum 154 kg | 340 lb Electrical Performance Frequency Attenuation (dB/100 m) Attenuation (dB/100 ft) 5 MHz 0.36 0.11 55 MHz 1.21 0.37 83 MHz 1.48 0.45 211 MHz 2.43 0.74 250 MHz 2.66 0.81 300 MHz 2.92 0.89 350 MHz 3.18 0.97 400 MHz 3.44 1.05 450 MHz 3.67 1.12 500 MHz 3.90 1.19 550 MHz 4.10 1.25 600 MHz 4.30 1.31 750 MHz 4.89 1.49 865 MHz 5.31 1.62 1000 MHz 5.74 1.75 Attenuation listed represents maximum values at standard condition of 20 °C (68 °F) Regulatory Compliance/Certifications Agency Classification RoHS 2011/65/EU Compliant ISO 9001:2008 Designed, manufactured and/or distributed under this quality management system Pallet Dimensions: 48”x48”x36” Pallet Weight: 1322 LBS (600 Kg)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	CommScope
MPN	5513502
Model	QR 715 JCASS PR2355
Country/Region of Manufacture	United States
