Compact THC3T-02 With Step/Dir Output, US $870 – Picture 0
Compact THC3T-02 With Step/Dir Output, US $870 – Picture 0

Compact Thc3t-02 With Step/dir Output

US $870

  • HoChiMInh, Province, Vietnam
  • May 28th
Open on mobile:
QR code
Compact THC3T-01 With Step/Dir Output Compact THC3T-01 With Step/Dir Output uses arc voltage to maintain a consistent distance from the plate while the torch is cutting. This allows the system to maintain proper torch height regardless of variations in the material, of flatness of the cutting bed. Specifications Using a potentiometer for change online the height of the torch. Voltage divider and noise to obtain the raw signal from the plasma cutting. Using signal processing algorithms to derive the voltage stability of the plasma. Apply  a algorithm to support smooth motion, this is a advantage of Compact THC3T-01  Auto detect ARC OK Auto calib the arc voltage with any plasma cutter. Control directly the Z axes driver with Step/Dir signal, give high performance and more accuracy. On IDLE mode, user can jog from software. Integrated Voltage Divider 1:50 This version is specify to integrated with Mach3 software.   Block diagram of Compact THC3T-01   Wiring to get the arc voltage value from plamsa cutter     MACH 3 configuration    Youtube Links: https://www.youtube.com/watch?v=i3_FV91WH3o https://www.youtube.com/watch?v=Kn9b6RyQoEA Manufacturer: 3T Robotics Group, Vietnam Contact Info We are ready to cooperate with individuals, organizations and companies in research and product development of plasma cutting machines. For more information about this product, please contact us by phone or email below. Phone: +84 974908615 Email:          sales@robot3t.com
