Complete Working Dorc Zx-1 Mini Interferometer Fiber Connector Tester ~ Wyko Fot

US $1366

Columbia, Maryland, United States
Jun 18th

Open on mobile:
QR code

Guaranteed working ZX-1 mini with cables, control hardware, computer, software and monitor. Manufacturer's Product Information: Description: Direct Optical Research Company DORC ZX-1 mini Interferometer Key Benefits Single unit can measure PC/APC connectors, ferrules, ferrule blanks, fiber cleaves, angled fiber cleaves and ribbon fibers Automated measurements for radius, apex offset, fiber height, key error and fiber/ferrule surface roughness using DORC's intuitive Windows XP ® Professional based PMS software Extremely accurate and repeatable non-contact measurements in less than 1 second Extensive reporting, archiving and statistical analysis capabilities Automated scratch analysis Integrated control of popular IL/BR meters Available with dual-source extended range, for measuring fiber heights up to + 6mm Compliance with all "Standards Organizations" measurement methods worldwide Electronically controlled zoom objective, inspection and interferometric modes Fully enclosed vibration and contamination insensitive design Solid state illumination - no bulbs to change Low maintenance and automatic calibration Product Information Direct Optical Research Company specializes in the design and manufacturing of non-contact interferometers for the optical fiber and connector industry. DORC's range of ZX-1 Zoom Interferometers and Phase Measuring System (PMS) software has been specifically designed to meet the ever-increasing need for accurate, automated, high volume testing of ferrules, ferrule blanks, connector assemblies, pigtails, patchcords, array connectors and optical fiber cleaves. DORC's implementation of the Michelson Interferometer incorporates an electronically controlled zoom objective. Fringes created by introducing an internal reference path can be analyzed to measure the surface topography of a connector or fiber endface. The fully enclosed vibration and contamination resistant Michelson configuration eliminates the requirement for the delicate surface of the sample under test to be in physical contact with the measuring equipment. Being non-contact not only avoids contamination of both the sample and interferometer, but also removes the possibility of contamination induced measurement errors. Specific Details: Radius of Curavture Reproducibility - One Sigma: 0.25% Repeatibility - One Sigma: 0.10% Apex Offset Reproducibility - One Sigma: 2.0 µm Repeatibility - One Sigma: 0.5 µm Fiber Height Reproducibility - One Sigma: 1.5 nm Repeatibility - One Sigma: 1.0 nm Radius of Curvature 3mm-Flat Apex Offset 0-500 µm (value calculated if outside of captured frame) Fiber Height ± 6 µm (with extended range option) Principle of Operation Michelson Interferometer (non-contact system) Measurement Speed Less than 1 second (standard range) Magnification X85 - X550 for ZX-1 mini using 12" monitor X60 - X400 for a ZX-1 mini PMS using a 15" XGA monitor and the digital zoom turned off Operating Wavelengths 665 nm (and 545 nm with extended range) Power Requirements for ZX-1 100-120V AC 50/60Hz (USA Version) 100-120V and 210-250V AC 50/60Hz auto sensing (International Version)
