Contec Digital 16-channel Eeg/electroencephy & Mapping System Kt88-1016

US $989.00

Beijing, China
Mar 4th

Open on mobile:
QR code

KT88-1018 Digital 18 channel Brain Electric Activity Mapping Introduction KT88 Digital Brain Electric Activity Mapping is an equipment for checking 16 channels of EEG and optional 2 channels of ECG, it collects EEG signal with electrodes, via integrated amplification, A/D transformation, PC auto-analysis, FFT, to form electroencephalogram which displays with color depth. The product is applicable for checking such diseases as epilepsy, intracranial inflammation, cerebrovascular diseases and brain tumors. Performance Parameter Channel: 18 channels of EEG + 2 channels of ECG(ECG is optional) Sampling rate: 100 Hz A/D transformation: 12 bits Input impedance: >=10M? Patient leak current: < 10µA Noise level: =90dB Magnification multiple: 10000 Filter constant: all digital and free enactment Display speed(paper speed): 5, 10, 15, 30, 60, 120 mm/s Amplitude: 1, 1.5, 2, 3, 5, 7.5, 10, 12, 15, 20, 30, 50 mm/50µV Playback speed: 1 time, 2 times, 3 times, 10 times, 20 times, 40 times, 60 times 50Hz interference suppression: >=30dB Safety type:Class II, type BF applied part Function Features Standard 18 channels of EEG, compatible with 18 channels and 8 channels function. Method of 10/20 electrodes placement under international standard system, montages can be changed during replaying(such as monopolar, bipolar or user-defined montages). Adopt bioelectricity amplifier for distilling brainwave, continuous record time can be up to 24 hours, integrated full-automatic calibration system. Powerful playback function: two playback modes(continuous and rolling) are optional, amplitude and display speed are adjustable. The special subdividing time line divides the waveform in one second into 5 parts, which is easy for doctors to look over the waveform. Multifunctional digital filter system provide different filter methods and window types, and user can freely set low-pass, high-pass, band pass and band stop filter. EEG signal clipping function, analyze and store any section of EEG wave, and select several segments waveforms for automatically analyzing and distilling to different parameters. Electronic frequency ruler, convenient to measure the basic information of any appointed EEG waveforms. With partial enlarging window, to accurately measure EEG period, amplitude and frequency, and which can be adjusted according to personnel judgment. Mark EEG wave under the events of opening eyes, closing eyes and flashing with different colors, and user-defined events can be added, waveform color for evoked event can also be set freely, ensures that the waveform in corresponding time can be rapidly found by event name during case playback. Powerful automatic analysis function, can carry through the power spectrum analysis and pathologic wave detection for appointed waveform. Many graphs can be displayed in the same screen, including kinds of BEAM, numerical BEAM, compressed spectrum graph, trend graph, and so on. Professional isolation transformer, dual power supply isolation system and optoelectronic data transmission to ensure security. Use USB interface to transmit data which just need to be inserted. Multifunctional flash stimulator of USB interface, and frequency can be controlled manually or automatically. A flash stimulation scheme can be set and performed in the process of collection. Perfect case management function, provides many means for research and quick statistic information; convenient case export and import function, and stores with CD-RW disk, which is easy for data research. Integrative image and character report, report can be edited in mode and switched to Word document. Case files can be transformed into EDF and BDF data format, convenient for data exchange, academic exchange and further analysis. System parameters and display modes can be set as required, which meets different user’s requirements. Add marks and annotations to the waveform designated, which can rapidly find the waveform in that time by marks. Optional video function: USB camera is easy to install, convenient to use and exact to record. With flexible playback function, which can browse the waveform of any time along with the corresponding isochronous collected image. SpO2 function which can view SpO2 value, pulse rate and SpO2 trend graph is optional. Accessories Standard accessories: Twenty EEG leads Two EEG leads(ear electrode) Two data lines Twenty EEG electrodes Two headgears One flashlight One flashlight power supply One disk One User Manual One earth wire Two aluminum blocks Optional accessories: ECG lead. ECG electrode(for optional ECG function) SpO2 module (one CMS-P SpO2 probe, one disk with software) Video module(one softdog, one camera, one video software disk) EEG bracket(tripod) Qualification Certificate SFDA, CMC 1.For the payment we accept Paypal Paypal account:ebaycontecmed@gmail.com 2.Pleae pay it as soon as possible then we can send the item in time. 1. All item will be shipped by China post within 1 business days. It takes approximately 12-25days(USA ,CA,AU,UK). And 15-35 days to other countries. 2. if you would like Express by EMS;you should pay an extra 15 USD shipping fee, it takes 5-12 workdays for delivery. By Airmail: Generally, about 2-3 weeks to UK, USA, AU. By Express: Generally, about 5-12 working days to UK, USA, AU,Canada. We can also ship the item through express service like DHL, UPS, if you are ready to pay the extra charge. To know the details please contact us with email. 3. All items will be shipped to buy's PayPal address. Please make sure your PayPal address is right.if you would like to send to other address,please contact me fistly. 4. The trade is cross-border and Airmail is the economic post way, so it take a long time for delivery. so we hope you can wait for it patiently.Thanks! 5. Buyer should be responsible for your Customs duty. Note: Please leave me your detail address and telephone number when you pay; please read the description of item carefully,thanks for your cooperation! Buy Safe Product! The following FDA Disclaimer is required for all eBay listing in Healthcare category and is included for REFERENCE: The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, do not bid on this item unless you are an authorized purchaser. If the item is subject to FDA regulation, We will verify your status as an authorized purchaser of this item before shipping of the item. Custom fee: International Buyers - Please Note: • Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. • Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying." Warranty: 3 years (1 year for spare parts) warranty from the date of shipment under normal use and service. we are the factory,If problems are found in the use of our products,please feel free to contact me, I will do my best to help you. We are looking for partners in the world now! Welcome to become our agent! Please contact : Eunice E-mail: contec.eunice@gmail.com Skype: eunice5187 Tel: 86-335-8015542 Fax:86-335-8015590 we are the original manafacurer, Contec Medical Systems Co.,Ltd

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Contec
Model	KT88-1016
