MS400 Multi-parameter Simulator Specification MS400 Multiparameter Simulator is a portable device, which can provide comprehensive physiological waveform to content general test and train requirement. It can check the monitor rapidly near the bed, also can test the quality warranty of ECG equipment, monitor and remote therapy equipment, At the same time, it can be used as the training of distinguishing from arrhythmia waveforms to the nurses. ?3.5-inch color TFT touch-screen, 320*240 pixels, friendly operation interface. ?Display the output waveforms synchronously, which is convenient for user to compare with the test equipment. ?It integrates the functions of SD socket interface, user can output the custom waveform by this device. ?Built-in templates list to provide the waveform that is expressed by each preset sequence number, which is convenient for searching. ?Two operation interfaces:Chinese and English. ?Operate with keystroke and touch-screen expediently and rapidly. ?Built-in 3.7V/4000mAh(Rechargeable alkaline battery). ?Optical external power: AC 220V, 50Hz or AC 120V, 60Hz ECG/Arrhythmia ECG ?Conventional: All leads have the same voltage with the II-lead as the reference ?Amplitude: 0.5,1.0,1.5 and 2.0mV ?The accuracy of Amplitude: ±2% ?ECG Rate: 15,20,25,30,40,60,80,100,120,140,160,180,200,220,240,260,280,300,320,340 and 350 BPM ?ECG artifacts: 50 or 60 Hz, muscle, baseline drift and breathing ?The elevation of the ST segment: -0.8 mV to +0.8 mV, the step is 0.1 mV ?The default: 80 BPM,1mV Arrhythmia ?Atrial: Atrial Fib(coarse), Atrial fib(fine), Atrial Flutter, Sinus Arrhythmia, Missed Beat, Atrial ?Tachycardia, Nodal Rhythm, Supraventricular Tachycardia ?Ventricular: Vent Fib (coarse), Vent Fib (fine), Premature Ventricular Contraction (PVC) 6/min, ?PVCs 12/min, PVCs 24/min, Freqent Multifocal, Bigeminy, Trigeminy, Paired PVCs, Run 5 ?PVCs, Run 11 PVCs, Vent Tachycardia, Asystole ?Premature Beat: Atrial Premature Atrial Contraction (PAC), Nodal PNC, Left Ventricular Focus ?PVC1, Early Left Ventricular Focus PVC1, Right Ventricular Focus PVC1, Early Right ?Ventricular Focus PVC1, R on T Left Ventricular Focus, R on T Right Ventricular Focus, Multifocal PVC ?Conduction Defects: First Degree Heart Block, Second Degree Heart Block, Third Degree Heart Block, Right Bundle Branch Block, Left Bundle Branch Block ECG Performance Testing ?ECG amplitude:0.5,1.0,1.5 and 2.0mV ?The accuracy of Amplitude: ±2% ?Pulse: 30 and 60 BPM, the width of pulse wave is 60 ms ?Square: 0.125 and 2.0 Hz ?Triangle: 2.0 and 2.5 Hz ?Sine: .0.5, 5, 10, 40, 50, 60 and 100 Hz ?ECG Rate:15, 20, 25, 30, 40, 60, 80, 100, 120, 140, 160, 180, 200, 220, 240, 260, 280, 300, 320, 340 and 350 BPM ?The accuracy of ECG Rate: ±1% Respiration ?Respiration Rate: 0 (Apnea), 15, 20, 30, 40, 60, 80, 100, 120 and 150 R/MIIN ?Respiration Impedance: 0.2, 0.5, 1.0 and 3.0 ? ?Baseline Impedance:500,1000,1500 and 2000 ?Apnea: 12 s, 22 s, 32 s ?ECG simulator with adjustable heart rate/12-lead output ?33 kinds of Arrhythmia waveforms ?Pacemaker ?Two IBP channels ?Variety of respiratory impedance,apnea pauses (0 BrPM) of 12, 22 and 32 seconds. ?Standard ECG calibration ?Export square,triangle and sine with adjustable frequencyIBP ?The default: 00/00mmHg ?Dynamic IBP Channel 1: Artery 120/80mmHg Radial 120/80mmHg Left Ventricle 120/00mmHg Right Ventricle 25/00mmHg Channel 2: Artery 120/80mmHg Radial 120/80mmHg Left Ventricle 120/00mmHg Right Atrium 15/10mmHg Right Ventricle 25/00mmHg Pulmonary Artery 25/10mmHg Left Atrium 14/4mmHg Static-Pressure Levels Channel 1: 0, 80, 160, 240, 320 and 400mmHg Channel 2: 0, 50, 100, 150, 200 and 250mmHg Buy Safe Product The following FDA Disclaimer is required for all eBay listing in Healthcare category and is included for REFERENCE: The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, do not bid on this item unless you are an authorized purchaser. If the item is subject to FDA regulation, We will verify your status as an authorized purchaser of this item before shipping of the item. 2 Paypal :ebaycontec.zheng@gmail.com Note: payment should be within 7 business days EMS :7-10 business days TNT: 5-7 business days if EMS service is not aviliable in your country! Netherlands, South Africa, Porto Rico, Yemen, and so on. Note: Please leave me your detail address and telephone number when you pay; please read the description of item carefully, thanks very much. All emails or questions will be replyed within 24 hours. 1.If you have a defective item, you want to return or discount. Please contact us within 2 days from you receive the shipment. All return items must be returned with it's original packaging and accessories. Customer is responsible for shipping charges on returned items. 2.we will refund the money to you when we get the return items. Or replace item for you. 3.Sometime Airmail miss some postage, we will refund price and shipping fee when you can not get your item. Country ship time State US, UK,CA,AU exceed 30days Refund Other Country exceed 35days Refund 4. We will deal with the refund in 2 business days when we get the info from you. Please read our trade Policy before buy , if you don't agree our trade policy please don't buy item from us. Item tracking number: we will provide to you after we send it out. International Buyers - Please Note: • Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. • Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying." We are the manufacturer of medical equipments for more than 18 years, the following are our main products: ECG ECG holter EEG EEG Holter B-ultrasound Patient Monitor Fetal doppler Fetal Monitor Spo2 Monitor Stethoscope Medical Image.... Welcome to contact us for FREE catalogue! Agent in the world! We are looking for partners in the world now! Do you want to become our agent in you conutry? Join US! Please contact : Lucy Yahoo ID & MSN: contec_lucylee@yahoo.com.cn E-mail: conteclucy@gmail.com Skype: contec_lucylee Tel: 86-335-8015542 Fax:86-335-8015590 Contec Medical Systems Co.,Ltd, Manufacturer, Qinhuangdao,China On Jul-22-14 at 08:40:52 PDT, seller added the following information:
