Contemporary Controls Bas Ethernet Switch; Model: Eiba5-100t/r

US $25.00

Statham, Georgia, United States
Mar 8th

Open on mobile:
QR code

IN WORKING CONDITION REMOVED FROM WORKING SYSTEM. GUARANTEED IN WORKING CONDITION. Features Compact Size 10BASE-T/100BASE-TX compliant Auto-MDIX ports Auto-negotiated data rate, duplex and flow control Panel and DIN-rail mountable versions Powered from an unregulated DC source (10–36 V) or an AC source (8–24 V, 47–63 Hz) via a quick-disconnect terminal strip. Full or half-duplex Activity/link and data rate LEDs Industrial environment EMC CE Mark UL 508 Listed, C-UL Listed Industrial Control Equipment Product Overview There is an expanding need for Ethernet switches in many of the new Building Automation Systems (BAS). The Plug-and-Play (PnP) EIBA switches provide the needed functionality, mounting convenience, and ruggedness to fill those applications. The popular EIBA5-100T which is designed for panel mounting is complemented by its DIN-rail cousin, the EIBA5-100T/R. Utilizing switching technology, the compact and low-cost EIBA switches provide five 10/100 Mbps shielded RJ-45 ports. Each port is Auto-MDIX compliant and can operate as an uplink port, eliminating the need for crossover cables. All ports automatically negotiate data rate, duplex, and flow control. EIBA switches address a key issue in building automation systems and that is convenient mounting in control panels. Office-grade equipment is intended for desktops, requiring a separate power supply powered from a 120/230 Volt AC mains circuit. In this situation, a shelf would be constructed to mount the unit and a receptacle would be installed inside the control panel. However, EIBA switches mount in subpanels and operate from the same source that powers other BAS equipment. These devices accept a wide-range, low-voltage AC or DC power source. The LEDs on these units face the technician for easy network troubleshooting. The label on the device can be written upon so port connections can be documented as to the location of connected equipment. Each port LED glows solid if a link exists, flashes to show activity and shows data rate by color: green for 100 Mbps and yellow for 10 Mbps. One power LED is provided. Unlike office-grade equipment, EIBA units are designed for commercial and industrial applications. The switches have a wider operating temperature range and comply with global industrial electromagnetic compatibility standards so there is no concern about installing them in harsh environments. They are UL 508 Listed for Industrial Control Equipment. EIBA switches will function with any Ethernet application such as BACnet/IP, BACnet/Ethernet and Metasys.

“WORKING CONDITION REMOVED FROM WORKING SYSTEM”

Brand	CONTEMPORARY CONTROLS
MPN	EIBA5-100T/R
Model	BAS SWITCH
