Cooper Wheelock Powerpath Ps-24-8mc Proprietary Power Supply Each Output 3.0 Amp

US $125.99

Fort Worth, Texas, United States
Mar 12th

Open on mobile:
QR code

Up for sale is an brand new,"Wheelock's PS-24-8MC (POWERPATH) 8 amp"Power Supply Charger offers 8 amps of 24V filter, regulated and supervised power. "BRAND NEW LOWEST PRICE EVER GET IT NOW ONE TIME DEAL" Wheelock, Inc. a leading provider of fire life safety, emergency communications and facility management products, has introduced a new POWERPATH 8 amp Power Supply Charger with 8 full amps of 24V filtered, regulated, supervised power. The PS-24-8MC is capable of handling 4 class B or 2 class A output circuits with 3 amp rating offers continuous or temporal coded out and can connect to any 12V or 24V panel using NAC inputs, dry contact closures or addressable modules. In addition, the new power supply/charger is UL Listed under UL Standard 864 9th edition and be used with any 24 volt Listed Regulated notification appliance. There is also an optional 4 class A plug-in module. The PS-24-8MC POWERPATH is an 8 Amp, 24VDC, filtered and regulated, supervised remote power supply/charger used for supervision and expanded power driving capability for Fire Alarm Notification Appliance Circuits. The PS-24-8MC may be connected to any 12V or 24V (FWR or DC) Fire Alarm Control Panel (FACP) by using a Notification Appliance Circuit (NAC) or a “Dry Contact”. Primary applications include NAC expansion (supports ADA requirements) and auxiliary power to support system accessories. This unit provides filtered and regulated 24VDC, 8 Amp up to four (4) Class "B", two (2) Class “A”, or two (2) Class “B” and one (1) Class “A” Notification Appliance Circuits. With the optional plug-in PS-4CA module 101648 the unit supports (4) Class “A” Notification Appliance Circuits. Additionally, an auxiliary power output of 3.5 Amps (disconnected upon AC power loss or an alarm condition) or 200 mAmps (constant) is provided, which can be manually reset. The PS- 24-8MC also contains a battery charger capable of charging up to 20 Amp/Hour (AH) of battery backup. Batteries larger than 12 AH will not fit inside cabinet, use of an external battery cabinet is necessary. Two FACP NAC circuits or two “Dry” contact initiating circuits can be connected to the POWERPATH inputs. These inputs can then be directed to control supervision and power delivery to any combination of the four (4) outputs. Each output is rated at 3.0 Amps (Class "B") or (Class "A") and can be programmed to generate a steady or Code 3 Temporal Horn sound and a strobe output under alarm condition. Total load for the PS-24-8MC NAC circuits shall not exceed 8.0 Amps. The PS-24-8MC under non-alarmed condition provides independent loop supervision for Class “A” and Class “B” FACP NAC circuits. In the event of a loop trouble, the FACP will be notified via the POWERPATH steered input (IN1 or IN2). In addition there are two sets of trouble reporting terminals, one used for AC power loss reporting and the other for all troubles. The AC power loss reporting, on the common trouble terminals, can be delayed for either 30 seconds or 170 minutes. The AC power loss terminals will always report the trouble, 30 seconds after loss of AC power. Wheelock horns/strobes, strobes and horns with synchronizing capability can be utilized with the PS-24-8MC. Audibles can be silenced with only two wires. Additionally, the POWERPATH can provide a temporal coded signal for appliances that can utilize it.
