Cortexa8 Ok335xd Single Board Computer/embedded Board With 4.3"lcd

US $360

???, ???, China
Jan 29th

Open on mobile:
QR code

NEWLY UPDATE Forlinx OK335xD has just pass the CE&FCC certification http://www.forlinx.net/?p=31&a=view&r=60 CortexA8 Based Single board computer Low cost development/Multi system support/Industrial design Industrial orientation Stable,Flexible,Easy-to-use OK335xD should be your BEST CHOICE!!! *Hardware Resource OK335xD CPU Module Features Key Parameter CPU TI AM335X Cortex-A8 processor, Max. 1GHz frequency. Nate: The standard main processor is AM3554 and the frequency is 720MHz/800MHz. CPU Structure Cortex-A8 Memory 512M DDR3 FLASH 256M SLC NandFlash Operating Temperature -40°C~+85°C Dimension 46mm X 70mm PMU TPS65217C Voltage 5V Humidity 10%~90% Systems Linux3.2/Android4.2/WinCE6.0/WinCE7.0/StarterWare Pre-installed System Linux3.2 GPU PowerVR SGX530 Function USB 2.0 1xUSB 2.0 Host Interface,1xUSB 2.0 OTG Interface Ethernet 2x Gigabit Ethernet Interface SD/MMC/SDIO 3xSD/MMC/SDIO Interface IIC 3 x IIC Interface SPI 2 x SPI UART / IrDA 6 x UART/IrDA Serial Port GPIOs Support ADC 8 x ADC Interface CAN 2 x CAN bus Interface EEPROM Support Video Encoder Software Codec 2D / 3D Support RGB Support Audio Interface IIS Interface OK335XD Base Board Features SPI 1xSPI Power 5V Instant Voltage Power Interface LED 4 x User LED LCD 4.3",5", 7", 8",10.4" resistive or capacitive LCD SD 1 x 32G SDHC card WIFI 1 x SDIO Interface is available for connection Serial Port 3 x Serial port (2 x RS323, 1 x TTL) USB Device 1 x USB Device USB Host 4 x USB 2.0 Host RTC On-board RTC chip RS-485 Bus 1 x RS-485 bus interface JTAG Support and is used for starterware debugging A/D 8xADC interface, 4 for resistive touch panel and 4 drawn out for user , IIC 2 x IIC interface Button 6 functional buttons Audio 1 x phone,interface, 1 x MIC interface, and 1 x line in interface Switch SD card boot or NAND flash boot Reset 1x reset button Ethernet 1 x Gigabit Ethernet interface CAN 1 x CAN bus interface PWM 1 x PWM interface is used for LCD backlight adjustment External Bus 12 bit address line and 16 bit data line *Software Resource Android4.2 OS Android Version Android4.2 supports exclusively(Software Full Open Sources) Kernel Linux-3.2.0 Flashing Flash image file to NandFlash via SD card; Flash image file to NandFlash via USB Cross Compiler arm-eabi-4.6 Development Environment Ubuntu12.04.2 LCD Display 4.3",5”, 7”, 8”,10.4" System Compilling Method One-key compilation Development Manual Android user manual Drivers NIC driver LED driver LCD backlight driver RTC driver Audio driver(I2S Interface) SPI driver Serial port(including 3 serial ports) Button driver Linux3.2 OS Kernel Linux-3.2.0(Software Full Open Source) PSP version:04.06.00.10 SDK version:05.07.00.00 Flashing Method Flash image file to NandFlash via SD card; Flash image file to NandFlash via USB U-boot U-boot-2011.09 Cross-compiler Cross-tools-am335x-4.5.3 Development Environment Ubuntu12.04 LCD Display 4.3",5”, 7”, 8” ,10.4"LCD. Resolution:800*480/800*600 File System ubifs Graphical System QT4.8 Drivers Equipment NIC driver LED driver LCD backlight driver USB interface U Disc USB mouse PWM driver Flash ECC verification Nand Flash driver UBI file system SD card driver LCD FrameBuffer Resistor touch screen driver RTC driver Audio driver(I2S Interface) SPI driver Serial port(including 3 serial ports) Button driver Watchdog driver RS-485 driver CAN driver Testing Programs SD card testing LCD testing(including resistor touch test) Button testing USB testing Wired LAN testing Serial port testing Audio testing Reset testing RS-485 testing CAN testing SPI testing Watchdog testing LED testing Backlight testing RTC testing EEPROM testing WinCE6.0/WinCE7.0 OS BootLaoder EBOOT supports USB2.0 high-speed download Flashing Flash image file to NandFlash via SD card; Flash image file to NandFlash via USB CE Edition WinCE6.0/WinCE7.0 (WinCE7.0 Software Full Open Source) PC Development Environment VS2005 and VS2008 LCD Display 4.3',5”,7”,8”10.4" LCD. Resolution Rate: 800*480/800*600 Driver Support LED driver GPIO driver IIC driver SPI driver Serial port driver SD card driver EMAC driver USB driver Backlight driver DMA driver EMAC driver Bare Computer Platform StarterWare Bare Computer Platform Support Furthermore, we could provide LCD in different dimension to satisfy various demands of customers: 5.6-inch, 7-inch(R),7-inch(C), 8-inch,10.4-inch LCD. ************************************************************************************************************************************************************************** *Payment terms Product could be paid on Ebay via Paypal. *Shipping terms 1.Product will be shipped within 3 working days after cleared payment. 2. Make sure to leave complete contact information, which contains Receiver name, Telephone number or Mobile phone number, Address,Post code. Most importantly, you must note that which operation system (Linux?WinCE?Andriod?) should be pre-installed in advance for your convenience. 3. DHL,FedEX, EMS,UPS,TNT is our preferred shipping method. 4. Tracking No. will be informed after the product is send out. 5. We are not responsible for the duty or charges occured in your local customs, of course, we would like to provide necessary assistance when help is needed. *Technical support terms As a real manufacture, we pride ourselves on technical support. We could offer aids in product selection and operation problems through email, telephone and instant messenger. *Returns terms 1. As for the products need to be exchanged, firstly, please contact us and send the photos of damaged products to us. We will estimate the damages then decide the best way to exchange or return the product. However, the case will not be accepted if the products were damaged by inappropriate use or carelessness. 2. If you wish to exchange defective or incorrect shipped goods, please contact us within 5 days after receiving the goods. And buyers should pay all additional shipping fees incurred and the items returned should be kept in their original status. *Feedback 1. Your feedback is very precious to us, we will try our best efforts to win your favorable comment, and of course it will be very appreciated if you leave positive marks. 2. Please contact us before leaving any negative or neutral feedback. We will work with you to solve any problems. Thank you!
