Crestron Tpmc-ch-imw - Cat5 Balanced Av Interface Wall Plate

US $1500

Santa Rosa, California, United States
Jun 22nd

Open on mobile:
QR code

Crestron TPMC-CH-IMW - CAT5 Balanced AV Interface Wall Plate The TPMC-CH-IMW is a wall plate version of the TPMC-CH-IMC interface module, providing a wall plate connection for new Isys® TPS and TPMC-CH series touchpanels that utilize Crestron Home® (CH) CAT5 Balanced AV connectivity*. It mounts into a 2-gang electrical box and includes front panel connections for a single "triamese" cable (provided with the touchpanel or sold separately). Several TPMC-CH-IMW wall plates may be installed to facilitate connectivity for a single movable touchpanel at multiple locations. Wired as part of a complete Crestron Home CAT5 AV distribution system, the TPMC-CH-IMW requires just a single CresCAT-D cable, carrying Cresnet, bidirectional audio, and (1) video signal up to 500 feet within a single bundled cable (observe distance limitations based upon power consumption for the touchpanel in use). The TPMC-CH-IMW can also be connected to conventional audio and coaxial video sources. *The TPMC-CH-IMW is not compatible with QuickMedia® or 10-pin RJ45 based systems. Connectors - Front Panel NET (1) 4-pin 3.5mm detachable terminal block; Pass-thru from rear NET port AUDIO (1) 8-pin RJ45 female; Bidirectional CAT5 balanced stereo audio port; Output Impedance: 100 ohms balanced; Maximum Output Level: 2 Vrms; Input Impedance: Infinite (unbuffered pass-thru to rear AUDIO OUT port) VIDEO (1) 8-pin RJ45 female, CAT5 balanced video output port; Output Impedance: 100 ohms balanced Connectors - Rear Panel NET (1) 4-pin 5mm detachable terminal block; Cresnet slave port, connects to Cresnet control network VIDEO COMP/Y/Y, C/Pb, Pr (1) 9-pin 3.5mm detachable terminal block; Provides (1) composite, S-Video, or component video input; Input Impedance: 100 ohms balanced (also accepts 75 ohm unbalanced); Input Level: 1 Vp-p nominal, 1.5 Vp-p maximum; Maximum DC Offset: 1.5 Volts; Connects to any Crestron CAT5 Video Out port via CresCAT cable, or a conventional coax video source AUDIO IN (1) 5-pin 3.5mm detachable terminal block Balanced/unbalanced stereo line-level input; Input Impedance: 20k ohm balanced, 10k ohm unbalanced; Maximum Input Level: 4 Vrms balanced, 2 Vrms unbalanced; Connects to any Crestron CAT5 Audio port via CresCAT cable, or conventional audio source AUDIO OUT (1) 5-pin 3.5mm detachable terminal block; Balanced stereo line-level output (unbuffered pass-thru from front AUDIO port); Connects to any Crestron CAT5 Audio port via CresCAT cable, or a conventional balanced audio input LED Indicators PWR (green) Indicates 24 Volts DC power supplied from Cresnet control network Power Requirements Cresnet Power Usage 2 Watts (0.08 Amps @ 24 Volts DC) Environmental Temperature 41° to 122°F (5° to 50°C) Humidity 10% to 90% RH (non-condensing) Enclosure 2-gang mountable in a standard electrical box (2.5 inch deep minimum); includes black metal front panel decorator style inserts; requires decorator style faceplate (provided by others) Dimensions Height 4.11 in (10.44 cm) Width 3.50 in (8.89 cm) Depth 1.66 in (4.22 cm) Weight 7.5 oz (0.21 kg) Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. Froo www.froo.com | Froo Cross Sell, Free Cross Sell, Cross promote, eBay Marketing, eBay listing Apps, eBay Apps, eBay Application
