Crusher 16" Series 30hp 4060 Claw Type Quiet Efficient Granulators

US $15,014.71

Cerritos, California, United States
Aug 5th

Open on mobile:
QR code

Short Description 1. Max output: 790-1300 lbs/hr 2. Cutting chamber: 23.62×14.17 inches 3. Screen size: 25/64 inch (10 mm) 4. Robust Construction for a long operating life. 5. Low noise level - Low Dust Generation on engineered plastics. Description QE Series Granulators Technical Details Type QE4060 Motor Power HP 30 Rotating speed Rpm 530 Material of blades SKD-11 Quantity of Rotating Blades Pcs 3×10 Quantity of Fixed Blades Pcs 2×2 Cutting chamber inch 23.62×14.17 Max. Output lbs/hr 790-1300 Regrind Conveyor o Cooling Device √ Full-receiver alarm device o Feed hopper with magnet o Dust separator o Weight lbs 3483 Screen size inch mm 25/64 10 Dimensions inch 61.42×40.35×71.97 Voltage Options: a. 230V ± 10% ,3 phase, 60 Hz; b. 460V ± 10% ,3 phase, 60 Hz; c. 110V, 3 phase, 60 Hz Additional Information Features: ·The whole machine is made of stainless steel. ·Its compact and sturdy construction decides its function would not be affected by long term usage. ·Heavy burden type bearing with oil-sealed device and soundproof ply can keep the unit from shocking and noise, and prevent the material from pollution. ·Equipped with protective device for motor and chained power-off system to ensure safe operation, and also equipped with protective device for the safe cleaning. ·Blade are made of imported material, SKD11, through special manufacture process and heat treatment, the blades become more durable. ·Special claw blade designs can crush any hard or soft material extremely easier. ·Adjustable blade can be sharpened up while blunt and reused to prolong its life. ·The separation design of the crushing chamber and material bin allows the mesh screen to discharge and clean easily. ·QE4060 has a unique cooling water cycle system, which transfers the heat produced to outside area,can prevent granulated material from lumping efficiently. Optional Features s Conveyor belt s Full-receiver alarm device s Feed hopper with magnet s Dust separator s Air blower Typical Applications s Injection molded runners and reject parts s Blow-molded parts and tops/tails s Extruded tubes and profiles s Edge trims from sheet extrusion s Wooden s Film and woven bag s Foam, fibres and composite materials Cutting chamber: - A ø 16 inch - B 19 ½ -26 inch Models: QE4060

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	QE
MPN	Does Not Apply
UPC	Does Not Apply
