Cypress Ez-usb Cx3 Rdk Denebola See3cam_cx3rdk

US $199.00

Mound, Minnesota, United States
Jun 9th

Open on mobile:
QR code

Denebola (See3CAM_CX3RDK) is a USB3.0 USB video class (UVC) reference design kit (RDK) developed by e-con Systems using the EZ-USB® CX3 USB3.0 peripheral controller from Cypress® Semiconductor. The Cypress EZ-USB® CX3 is a USB3.0 peripheral controller that enables developers to add USB3.0 connectivity to any image sensor compliant with the Mobile Industry Processor Interface (MIPI) Camera Serial Interface Type 2 (CSI-2) standard.The Denebola RDK developed using EZ-USB® CX3 is a complete RDK and has the OmniVision® OV5640 CMOS image sensor interfaced to it through a two-lane MIPI CSI-2 interface. This is a fully functional camera RDK that can stream uncompressed 720p60, 1080p30, and 5 MP at 15 fps. Denebola RDK is a two-board solution containing a base board designed around the Cypress CX3 USB3.0 peripheral controller and the camera daughter board designed using the OmniVision® OV5640 CMOS image-sensor-based autofocus camera module. e-con Systems, a Silver level partner of Cypress Partner program, has developed this reference design kit for EZ-USB® CX3 from Cypress Semiconductors. Kit Contents: Denebola CX3 RDK (with e-CAM59CX3 camera board) USB 3.0 Type-A to Micro B cable Quick Start Guide http://www.e-consystems.com/CX3-Reference-Design-Kit.asp Two board solution containing baseboard based on CX3 and camera daughter board based on e-CAM52_MI5640_MOD Two-lane MIPI CSI-2 interface between the CX3 and OV5640 camera image sensor Optional daughter boards supporting various CMOS image sensors planned RS232 level UART port for debugging and other communication SPI Flash and I2C EEPROM for firmware storage. Default firmware is already loaded in the kit JTAG interface for debugging the firmware User Configurable GPIOs from the GPIO header OmniVision OV5640 daughter board interfaced through 2-lane MIPI CSI-2 interface USB bus powered. Support for external 5V supply through a switch Maximum frame rates for Preview and Capture VGA – 60 fps HD (720p) – 60 fps Full HD (1080p) – 30 fps 5MP (2592x1944) – 15 fps Still Image Capture 5MP (2592x1944) resolution YUV422 (16its per pixel) format Preview format: YUV422 (16bits per pixel)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Cypress
MPN	EZ-USB CX3 RDK
Model	EZ-USB CX3 RDK
