Cytron 20a 6v-30v Dual Dc Motor Driver

US $30.45

Swanton, Vermont, United States
Jul 14th

Open on mobile:
QR code

Description Cytron 20A 6V-30V Dual DC Motor Driver Enables bidirectional control for two brushed DC motors Features four buttons for quick testing Provides PWM frequency up to 20 kHz Compatible with sign-magnitude and locked-antiphase PWM operation Lets you overcurrent protection with active current limiting The Cytron 20A 6V-30V Dual DC Motor Driver enables bidirectional control of two high-power brushed DC motors from 6 V to 30 V. The onboard test buttons and motors output LEDs allow a functional test of the motor driver in a quick and convenient way without hooking up the host controller. This motor driver can be controlled with PWM and DIR inputs. With input logic voltage range from 1.8 V to 12 V, it’s compatible with a wide variety of host controllers (e.g. Arduino, Raspberry Pi, PLC). Note: Power input does not have reverse-voltage protection. Connecting the battery in reverse polarity will damage the motor driver instantaneously. Specifications Power Input Voltage: DC 6 V to 30 V Maximum Motor Current (Each Channel): 20 A continuous, 60 A peak Logic Input Voltage (PWM & DIR): Low Level: 0-0.8 V | High Level: 1.5-30 V PWM Frequency (Output frequency is same as input frequency): Standard: DC 20 KHz | Extended *3 20-40 KHz What's Included 1 x 20Amp 6V-30V DC Motor Driver (2 Channels) 4 x PCB Spacer Dimensions Size 78.74 x 88.90 mm (L x W)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Cytron
Type	Cytron
MPN	MDD20A
UPC	Does not apply
