Cytron 25a 7-58v Single Brushed Dc Motor Driver

US $51.45

Swanton, Vermont, United States
Jul 14th

Open on mobile:
QR code

Description Cytron 25A 7-58V Single Brushed DC Motor Driver Features bidirectional control for one brushed DC motor Offers overcurrent protection with active current limiting Provides temperature protection and under voltage shutdown Includes buttons for quick testing and LEDs for motor output state The Cytron 25A 7-58V Single Brushed DC Motor Driver is a high voltage single channel bidirectional motor driver for brushed DC motor from 7 V to 58 V. With discrete NMOS H-Bridge design, this motor driver is able to support 25 Amp continuously without an additional heatsink. The onboard test buttons and motor output LEDs allow a functional test of the motor driver in a quick and convenient way without hooking up the host controller. Buck regulator which produces 5 V output is also available to power the host controller. This is especially useful for high voltage application where no additional power source nor high voltage buck regulator is needed. Specifications Operating Voltage: DC 7V to 58V Maximum Motor Current: 25A continuous, 60A peak 5V ouput for the host controller (250mA max) PWM/DIR Inputs compatible with 1.8V, 3.3V, 5V, 12V and 24V logic (Arduino, Raspberry Pi, PLC, etc) PWM frequency up to 40kHz (Output frequency is fixed at 16kHz) What's Included 1 x MD25HV 1 x Potentiometer with connector 1 x Rocker switch with connector 4 x Nylon PCB Standoffs/Spacers Dimensions Size 106.68 x 60.96 x 55.88 x 111.76 mm

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Cytron
Type	Cytron
MPN	MD25HV
UPC	Does not apply
