Cytron Dual 10A Motor Driver HAT for Raspberry Pi, US $23.38 – Picture 0
Cytron Dual 10A Motor Driver HAT for Raspberry Pi, US $23.38 – Picture 0

Cytron Dual 10a Motor Driver Hat For Raspberry Pi

US $23.38

  • Corona, California, United States
  • Aug 16th
Open on mobile:
QR code
HAT-MDD10 is designed to drive two high current brushed DC motors up to 10A continuously by using Raspberry Pi as the controller. It offers signed-magnitude PWM control of direction and speed.  Features: Bi-directional control for two brushed DC motor.     Support motor voltage ranges from 6VDC to 24VDC.   On board test button for manual control of motor. Every channel output built with LED indicator.  Maximum current up to 10A continuous (without heatsink at 25) and 30A peak (10 second). Current limiting at 30A.    Raspberry Pi compatible connector.     Solid state components provide faster response time.    Fully NMOS H-Bridge for better efficiency and no heat sink is required.    Speed control PWM frequency up to 20KHz (Actual output frequency is same as input frequency from Raspberry Pi). Support sign-magnitude PWM operation.    Support TTL PWM from microcontroller, not PWM from RC receiver. Dimensions:  67.5mm x 59mm Pi 3 fitted with PN00218-CYT1 Pi HAT (Pi 3, screws and spacers are not included with this sale) Here's a video demo of using this Pi HAT: https://www.youtube.com/watch?v=H1EPEOBd1LA
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Modified Item No
Custom Bundle No
Non-Domestic Product No
MPN HAT-MDD10
Brand Cytron
UPC Does not apply
