Dakota Ultrasonics Zx-3 Ultrasonic Thickness Gauge

US $1,525.00

Wilmington, North Carolina, United States
Aug 3rd

Open on mobile:
QR code

Dakota Ultrasonics ZX-3 Ultrasonic Thickness Gauge Model: ZX-3 | Order No:Z-302-0001 Featuring a rugged thickness gauge with the ability to locate blind surface pitting and internal defects/flaws in materials. Based on the same operating principles as sonar, it is capable of measuring the thickness of various materials with an accuracy as high as ±0.001". Brand: Dakota Ultrasonics Model: ZX-3 Order No: Z-302-0001 Condition: NEW Description Dakota Ultrasonics ZX-3 Ultrasonic Thickness Gauge Features Powered by 120 MHz FPGA timing 150 volt square wave pulser Pulse-echo measurement Adjustable gain (40 to 52 dB), in 3 dB steps (vlow, low, med, high, vhi) Selectable manual or auto zero Dual element transducers (1 to 10 MHz options) Low temperature custom LCD display (-22°F/-30°C) Selectable probe diameter for improved linearity High speed scan: display the lowest reading found during a scan. Scan speed at 100 Hz IP65 protection rating 5 year limited warranty Applications Corrosion and pitting Tube and pipe Tanks Boilers Glass Included Dakota Ultrasonics ZX-3 Ultrasonic Thickness Gauge Specifications Range Measures from 0.025 to 36.00" (0.63 to 914.4 mm); range dependent on material and transducer type Units English & Metric Resolution 0.001" (0.01 mm) Velocity Range 0.0120 to 0.7300 in/s (305 to 18,542 m/sec) PRF 200 Hz Display Update Rate 10 Hz Gain 40 to 52 dB range in 3 dB steps Display Multi-function 7 segment 4.5 digit liquid crystal display with 0.500"digit height Two 0.125" 14 segment fields for labels and values, and one 7 segment field for labels and values Additional icons to indicate features and modes Backlight is selectable on/off/auto, and selectable brightness (Lo, Med, Hi) options Bar graph indicates stability of reading Power Source 2 x 1.5 V alkaline, 1.2 V NiCad, or 1.5 V Lithium AA cells Typically operates for 45 hours on alkaline and 23 hours on NiCad Low battery indicator on display. Auto shut-off after 5 minutes of inactivity Certification Factory calibration traceable to NIST & MIL-STD-45662A Operating Temperature -22 to 167°F (-30 to 75°C) Dimensions 2.5 x 5.17 x 1.24" (63.5 x 131.3 x 31.5 mm) Weight 0.69 lbs (11 oz) with batteries Terms & Conditions Item Condition: Unless specified otherwise all products listed are Brand New in the original factory packaging and include a full factory warranty. Shipping: We currently only ship to U.S. buyers. We ship items within one or two business days from payment. We do not process shipments on weekends and holidays. Local pick up is not available. We only ship to addresses verifiable by either PayPal or credit card issuing bank. Please note that we cannot alter the address once a purchase is made. In the case of PayPal payment, we will ship orders when the payment is marked “Eligible” for PayPal Seller’s protection. *Shipping Rates are for Continental US, Please Contact us for other US Destinations Payment: Currently all payments must be made directly though PayPal Sales Tax: We are required to charge sales tax in North Carolina Return Policy: If for any reason you are not 100% satisfied with a product you receive from us, you may return the regular stock product within 30 days from the time of receipt, for a full refund or exchange of the product you purchased (less any shipping costs). Within this time, products may be returned; freight prepaid and must be in their original packaging and in resalable condition. Shipping errors, missing items or damages mustbe reported to us immediately (damages should be accompanied by a signed bill of lading acknowledging the damage). Items returned will be inspected for damage or misuse at which time they may be subject to restocking fees, other fees or refused, prior to the issuance of any credit.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Dakota Ultrasonics
MPN	ZX-3
