Daoki 3d Printer Cnc Controller Kit With Ramps 1.5, Board For Arduino, Drv8825

US $48.19

Phoenix, AZ, United States
Jul 28th

Open on mobile:
QR code

DAOKI 3D Printer CNC Controller Kit with RAMPS 1.5, Board for Arduino, DRV8825 Specification: RAMPS 1.5 Board: Input voltage: 12V Power: 200W Patch MOS tube: B55NF06 Size: 101.5 x 60.5mm Board for Arduino: Microcontroller:ATmega2560 OperatingVoltage:5V Input Voltage (recommended):7-12V Digital I/O Pins54 (of which 15 provide PWM output) Analog Input Pins:16 DC Current per I/O Pin:20 mA DC Current for 3.3V Pin:50 mA 256 KB of which 8 KB used by bootloader SRAM: 8 KB EEPROM:4 KB Clock Speed:16 MHz Mechanical Endstop Limit Switch: Length of Cable: 70 cm /27.6" Size: 32 x 10mm Connector: Red line connecting VCC (ramps of +) Connect the black wire GND (ramps of -) Green Line connection SIGNAL (ramps in s) DRV8825 Stepper Motor Driver Module: 1.Six different steps resolutions: full step, half step, 1/4-step1/8-step1/16-step, 1/32-step 2.CAN interface directly with 3.3 V and 5 V systems 3.Over-temperature thermal shutdown, overcurrent shutdown, undervoltage lockout 4.Short to ground short circuit load protection 5.4 Layer 2 oz copper PCB, in order to improve heat dissipation 6.Exposed solder ground below the bottom of the driver IC on the printed circuit board pad 7.Adjustable current control lets you set a potentiometer, which lets you use the stepper motor's rated voltage or more, in order to achieve a higher rate of maximum output current step 8.Maximum 45 V supply voltage Package Included: 1 x RAMPS 1.5 1 x Board for Arduino 5 x DRV8825 Stepper Motor Driver 5 x Heatsink 1 x LCD 12864 Display Module 1 x USB cable 1 x DC Power Cable 20 x Jumper Cap 4 x Mechanical Endstop 2 x FC Cable 1 x L Type Adapter Plate 1 x Phillips Screwdriver RAMPS 1.5 change the original plug-in MOS tube to patch-type MOS tube in order to solve the problem of plug-in MOS tube easy to break, take up a large area, poor heat dissipation , which can improve the stability and aesthetics of the board; The features of multiple extended interface and replaceable parts make RAMPS1.5 become a control board with powerful upgrade capability and scalable modularity. The board for Arduino use ATMEGA16U2 chip, Faster transfer rates and more memoryMicrocontroller:ATmega2560 LCD 12864 with Controller: This full graphic Smart Controller contains a SD-Card reader, an rotary encoder and a 128 x 64 dot matrix LCD display. You can easy connect it to your Ramps board using the "smart adapter" included. Package Content:1 x RAMPS 1.5, 1 x Board for Arduino, 5 x DRV8825 Stepper Motor Driver, 5 x Heatsink, 1 x LCD 12864 Display Module, 1 x USB cable, 1 x DC Power Cable, 20 x Jumper Cap, 4 x Mechanical Endstop, 2 x FC Cable, 1 x L Type Adapter Plate, 1 x Phillips Screwdriver

Condition:	New – Open box: An item in excellent, new condition with no functional defects. The item may be missing original packaging and may have been used for testing or demo purposes. The item includes accessories found with the original product and may include a warranty. See the seller's listing for full details and description. ...	Color	Ramps 1.5
Model	Does not apply
MPN	Does not apply
Brand	DAOKI
UPC	Does not apply
ISBN	3494370804899
EAN	Does not apply
