Data Connect Ig144s-lv Modem

US $33

Olney, Maryland, United States
Nov 11th

Open on mobile:
QR code

Data Connect IG144S-LV Modem The Data Connect DCE/IG144S high-speed V.32bis security dial-line modems are designed and manufactured for rugged industrial applications over the Public Switched Telephone Network (PSTN). The DCE/IG144 utillizes the industries latest V.32bis modem technology to deliver outstanding features, performance, and reliability in one cost-effective solution.The DCE/IG144S modem are ideally suited for industrial communication applications including SCADA systems, RTS, traffic monitor and control, and industrial automation networks.The DCE/IG144S supports RTUs equipped with an EIA RS-232 or RS-485 serial port. Data communications speeds up to 14.4 kbps in reception and up to 9.6 kbps in transmission are supported. . The modems incorporate the latest data-compression and error correction standards for improved data transmission and reception over marginal and poor-quality telephone lines. Multiple levels of security with password verification and security call back keep your valuable data secure from intruders.The DCE/IG144S modems are powered by a wide range of AC and DC power supply voltages. Its low power consumption and low stand-by current technology design makes the DCE/IG144S ideal for a battery-powered system as well as regular AC powered operations. Specifications Data Rate Support Data modem: ITU-T V32bis: Up to 14.4 kbps V.32bis: Up to 14400 bps V.32: Up to 9600 bps V.22bis: Up to 2400 bps V.21: 0-300 bps Bell 212A: 1200 bps Bell 103: 0-300 bps Fax modem: Send and receive fax up to 14.4kbps V17, V29, V27ter and V21 channel 2 EIA/TIA 578 Class 1, T.31 Class 1.0, and Class 2 Data format: Asynchronous, 7, 8, or 9 data bits, parity, 10- or 11 –bit character with 1 or 2 stop bits Modulation fully compatible with ITU-T V.32bis/V.22bis/V.21 Bell 212A and Bell 103 compatible modes Transmission Line Interface 2-wire full duplex over PSTN Connector: RJ-11C DTE/RTU Interface The modem provides serial ports to support RS-232 or RS-485 (selectable) interface standards: RS-232 Interface Connector: DB9-F Signals: RTS, CTS, CD, TD, RD, DTR, DSR, RI RS-485 Interface Connector: RJ-11C Signals: 4-wire full-duplex or 2-wire half-duplex TX+, TX-, RX+, RX- Front Panel Indicators LED Indicators: DTR, TXD, RXD, DCD, DSR, RI Security Options Password Log-in Security call-back Power Supply Specification Three models support various power options: Standalone: 90 – 264VAC Standalone: 100 – 400VDC Standalone: 10-48VDC Power Consumption: Idle mode: 65mA@12V, 0.78watts Normal mode: 75mA@12V, 0.9 watts, typical Mechanical Specifications Enclosure dimensions: 4.1” (W) x 5.0” (L) x 1.3” (H) 104mm (W) x 127mm (L) x 33mm (H) Weight: 0.5lbs, without AC power module Environment Specifications Temperature: Operation: -40° to +85°C Storage: -40° to +85°C Humidity: Up to 95% non-condensing Dry Contact Detection (optional) Two optical isolated dry contact detections are provided for external devices (consult factory for additional information). Key Features Worldwide Operation Support: – ITU-TV.32bis/V.32 – V.22bis/V.22/V.23/V.23/V.21 – Bell 212A/Bell 10 3 – V29 FastPOS – V.22bis fast connec t Security Options: – Password log-in – Security call-back Data Compression: – V.44/V.42bis/MNP 2 Error Correction : – V.42/MNP 2/MNP 4 DTE/ Host Interface EIA RS-232 and RS-485 Embedded AT command set Sixty-three embedded and upgradeable country profiles for worldwide homologation NVRAM for configuration and country profile storage Built-in remote diagnostics and configuration management Heavy-duty surge protection provided at power supply and phone line interface Supports wide range of AC & DC power supply options Supports DC power supplied from DTE or DB-9 connector Wide range of operating temperatures Optional mounting kits for DIN Rail mounting or wall mount Ordering Information DCE/IG144S Standalone with AC power module, 90-264VAC DCE/IG144SDC Standalone, DC power, 10-48VDC DCE/IG144-S-HV Standalone with AC power module, 90-264VAC or 100-400VDC DCE/IG202T-DIN DCE EN2 Din Rail Kit
