Data Connect Ig202trm-r38 Industrial Modem [dce/ig202trm-r38]

US $788

Olney, Maryland, United States
Nov 18th

Open on mobile:
QR code

DATA CONNECT IG202TRM-R38 BELL 202T 0-1200BPS RACKMOUNT 2/4WIRE & MULTIPOLLING10-48VDC DATA CONNECT IG202T-R38 BELL 202T 0-1200BPS STANDALONE 2/4 WIRE LEASED LINE & MULTI POLLING 10-48VDC The Data Connect IG202T-R38 is Bell 202 frequency shift key (FSK) and quadrature amplitude modulation (QAM) modem for asynchronous and synchronous data transmission in 300-3400 Hz voice band. It is highly immune to interference and noise and permits extensive voice-band communication link utilization. The modem supports several international standards ITU V.21, V.23, R.35, R.37, R.38A, R38B, v.29, Bell 103, Bell 202 and propriety Cegelec 1200/600Bd and Indactic 33 communication standards. The modem can operate in half or full-duplex, point-to-point or point-to-multipoint mode when using FSK modulation the receive and transmit channels may be independently set. The modem employs advanced DSP technology, thus offering high service flexibility through programmable features. Software configuration is performed via Hayes AT command set. AT commands can be initiated from any terminal application using and RS-232 communication interface. Additionally, for easy firmware upgrade a bootstrap loader is provided. The modem features programmable modem capability for SCADA or power utility communication networks. It can support a range of standards including ITUR.35, R.37, R.38A, R.38B, V.21, V.23, Bell 103, and Bell 202. It is fully programmable via Hayes AT command set. The modem also features specialized line, power line carrier, or radio communication, as well as half or full-duplex operating modes. The IG202T-R38 is designed for use in SCADA systems mainly based upon power utility communication networks. Depending on modulation standards it can communicate through specialized, private or leased lines, radio links and power lines (PLC) The IG202T-R38 is available as a desktop modem or in two different types standard 19” rack, including: 1U rack with 1, 2, or 3 modems per rack; 3U rack with 10, 12 or 14 modems per rack, with additional blank front plates covering unused slots. All connectors at the rear side are accessible at the back openings. Specifications Operation Type Data Transmission on audio frequency analog medium. Media Leased line, radio, PLC Modes -asynchronous or synchronous, point-to-point, 2-wire or 4-wire -support for synchronous Indactic 33 protocol. Interfaces DTE INTERFACE -RS-232C, DB (female) connector -Signals: DCD, RD, TD, DTR, SG, DSR, RTS, CTS, RI -Character length: 5-9 data bits, 1 start & 1 stop -RTS/CTS delay: adjustable by 1ms step within range of 40-6825ms -option to transmit on RTS -configuration: AT command set Analog Line -DB15 (female) connector -600O or high impedance with return loss
