Datakom Da-0303 75/150v 72x72 Three-phase Digital Ammeter

US $49.20

Gori, Georgia
Mar 26th

Open on mobile:
QR code

FEATURES True RMS measurements AC RMS current in three-phase systems. Adjustable Current Transformer Ratio Reduced panel depth Wide operating temperature range Sealed front panel (IP54) Plug-in connection system DESCRIPTION These state-of-the-art panel meters are designed for accurate measurement of the AC RMS current in three-phase systems. Although they are mainly used in electrical panels , these devices can also be integrated in many other applications. The current transformer ratio can be set between 5/5A and 5000/5A via front panel buttons. Devices have separate inputs for supply and measurement. TECHNICAL SPECIFICATIONS Power Supply Input: 75 - 150 V AC 50 - 60 Hz nominal (± 10%) Different AC/DC supply values available. Measurement Inputs: 0.2 – 5.50 A AC 30 - 100 Hz Accuracy: 0.5% + 1 digit Power Consumption: < 1.5W Burden: < 1VA per phase Operating Temperature: -40°C ;+80 °C Maximum Humidity: 95% non-condensing. Degree of Protection: IP 54 (Front Panel) IP 30 (Back panel) Enclosure: Non-flammable, ROHS compliant, high temperature ABS/PC (UL94-V0) Installation: Flush mounting with rear retaining brackets Dimensions: 78x78x41mm (WxHxD) Panel Cutout Dimensions: 68x68mm Weight: 145 gr EU Directives Conformity: 2006/95/EC (low voltage) 2004/108/EC (EMC) Norms of reference: EN 61010 (safety requirements) EN 61326 (EMC requirements) PACKAGING INFORMATION Pieces per Package: 24 Pcs Package Size: 280 x 170 x 215mm (LxWxH) Package Weight: 3.7 kg Check out my other DATAKOM products for generator sets: J1939 Communication Units Synchronization Units Automatic Mains Failure Units Remote Start Units Manual Start Units Automatic Transfer Switches Battery Chargers Alternator Voltage Regulators Panel Measurement Units Earthquake Units Telecommunication Units Extension Units -------------------------------------------------------------------------------------------------------------- We have a long time experience in international sales and make delivery only with traceable service. -------------------------------------------------------------------------------------------------------------- E-mail: info@controllers4generators.com Other datakom products on www.controllers4generators.com ALL CUSTOMS FEES IN COUNTRY OF DESTINATION ARE UNDER BUYER'S RESPONSIBILITY

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	DATAKOM
generator controller, set	automatic
Model	DA-0303 72x72
