Dataman 48uxp Universal Programmer

US $1,195.00

Vancouver, British Columbia, Canada
Jan 30th

Open on mobile:
QR code

Quick Overview Universal 48-pin chip programmer with USB 2.0 and parallel connectivity. Dataman 48UXP features intelligent hardware, including microprocessor and FPGA, allowing it to program devices you use today and the devices of tomorrow. Optimized for both laboratory and production the Dataman 48UXP is intelligent, fast and easy to use. General The Dataman 48UXP's on-board intelligence reduces system overhead to a minimum. This gives a 100% performance increase over its predecessor when programming high-density flash devices e.g. Intel 32 Mbit flash chip in less then 60 seconds The Dataman 48UXP performs device insertion and contact checks before programming each device. It can detect poor pin contact and devices inserted upside down or in the wrong position preventing expensive chip damage due to operator error The Dataman 48UXP's universal pin driver capability lets it program all 48-Pin DIL devices, including all single-chip Micro-controllers, without DIL-to-DIL adapters The Dataman 48UXP has additional safety features such as a built-in current limit and pin continuity check function. This prevents damage from faulty chips during the programming cycle Included with the Dataman 48UXP is a 44-Pin universal adapter that enables you to support 44-Pin chips such as EPLD, EPROM, Flash, EPLD and Micro-controllers, eliminating the need to buy multiple adapters The Dataman 48UXP supports 2.0V ~ 5.0V logic level input/output and can supply 2.0V ~ 21V analogue voltages such as VCC. Low voltage support (1.8V) is also possible by a low voltage adapter Programmer Specification Base Unit (DAC) USB 2.0 port FPGA based IEEE 1284 slave printer port, up to 1MB/s transfer rate On-board intelligence: powerful microprocessor and FPGA based state machine Power: 100 to 240 VAC, auto-switching Frequent range: 47 to 63 Hz Power consumption: 25 W Operating temperature: 5 to 45°C (41 to 113°F) CE & LVD certified ZIF Socket 48-pin DIL/ZIF socket with receptacle for 8-Pin to 48-Pin 300/600-mil devices Four DACs for Vcc, Vpp1, Vpp2 and Vpp3 with 8-bit resolution. Software controllable rises time and current limit protection. Logic driver supports pull-up/ pull-down or high impedance on all 48 pins with 2.0V-5V level http://www.dataman.com/dataman-48uxp-universal-programmer.html User Interface Many EPROM and Flash memories have a build-in device ID and manufacturer ID. The Dataman 48UXP can read the device's ID by press hot key to detect the ID and compare its database and determined the chip's correct vendor and product number. This feature is especially useful with second-hand chips and devices that have had their part number accidentally removed To meet mass-production requirements the Dataman 48UXP has implemented new patented technology in both its hardware and software. After entering the Mass-production Mode, the production line operator inserts a device into the ZIF socket. An LED on the Dataman 48UXP indicates the device is ready and the operator simply removes it and replaces it with a new one. The Dataman 48UXP's auto-sensing feature ensures the device has been inserted correctly and then automatically programs the device. In the mass-production mode the system keyboard is automatically disabled preventing the operator from making any inadvertent mistakes and with no formal training necessary adds flexibility, saves time and money User can create and save a project file which contains device selection, buffer data and all the programming set-up options. This project file can then be loaded for future use reducing set-up times The Dataman 48UXP has an Auto Increment function which simply increments the serial numbers in the buffer each time a new device is inserted, saving time and money User-selectable verify voltage with one or two-pass verification. This feature ensures that your device has been programmed properly, preventing failures due to programming errors and ensuring data retention Accepts JEDEC test vectors up to 48 pins Automatic file format detection and conversion: JEDEC, POF, Binary, Intel HEX, Intel EXT HEX, Motorola S, HP 64000ABS, Straight Hex and TEKTRONIC Hex Device Support The Dataman 48UXP supports over 32,000 of the most popular devices in use today – with future devices being added every day. Dataman 48UXP coverage includes the following device types: ZIF Socket BI-PROM EPROM EEPROM EPLD CEPAL CDLD CPAL CPLD GAL Flash FPGA MACH MROM NVRAM PAL PEEL PLD PROM SPLD Microcontrollers More Views Device Selection Blank Checking Load File to Buffer View and Edit Buffer Memory Device Operation Options Device Programming Dataman 48UXP Universal Production Programmer Dimensions: 310 x 170 x 40mm (12.2 x 6.7 x 1.6inches) Weight: 1.9Kg (4.18lbs) Operating voltage: 100-240V AC Power consumption: max. 25W active FREE SDP-UNIV-44 universal 44 pin PLCC adapter Moulded USB and Parallel Cable User Manual Software Compatible with Windows 2000, Windows XP, Windows Vista (32-bit only), Windows 7 and Windows 8 Optional range of adapters and socket converters also available The Dataman 48UXP universal programmer comes with: 30 Day Money Back Guarantee* - If you don't like it, send it back. Three Year Guarantee - Three years parts and labour warranty, on the 48UXP universal device programmer. Life-Time Technical Support - 48UXP technical support is available free via our website and telephone helpdesk for life. Two Year Software License - 48UXP software updates are available free for two years via our website. *Applies to orders from UK/US offices only. 40Pro S6 48Pro2C 48UXP 48Pro2 48Pro2AP Type Universal • • • • • • Multi Socket Stand-Alone Specialised Sockets 1 x 40-pin • 1 x 48-pin • • • • • Socket Mechanism Manual or 3rd Party Handler • • • • • • Automatic by Built-In Actuators Device Support Number of Supported Devices 31,000+ 15,000+ 82,000+ 32,000+ 83,000+ 55,000+ Low Voltage Support • • • • • • High Current/Voltage Legacy Support • • • Features Self Test • • • • • • Insertion Test • • • • • • ESD Protection • • • • • ISP Capability • • • • Multi-Programmer Capability • • • • Interface to PC USB • • • • • • Parallel • • Power Supply USB Powered • Mains Powered • • • • • O/S Support Windows XP • • • • • • Windows Vista • • • • • • Windows 7 • • • • • • Windows 8 • • • • • • Dimensions/Weight Width (mm) 160 136 195 310 195 88 Depth (mm) 95 90 140 170 140 205 Height (mm) 35 20 55 40 55 61 Weight (Kg) 0.5 0.3 0.9 1.9 0.9 1.1 Warranty/Support Parts and Labour (Years) 3 3 3 3 3 3 Life-Time Technical Support • • • • • • Life-Time Software Updates • • • • • Programming Speed (program/verify) Microchip 24FC128 00:05.9 00:06.4 00:02.3 n/a 00:02.3 00:02.3 ST M25P20 00:12.0 00:02.8 00:03.0 n/a 00:03.0 00:03.0 Intel QB25F640S33 05:06.0 00:24.0 00:30.7 06:50.3 00:30.7 00:30.7 SST SST39VF016Q 04:40.0 00:11.1 00:40.8 n/a 00:40.8 00:40.8 AMD Am29DL640G 04:40.0 00:28.0 00:24.0 03:27.7 00:24.0 00:24.0 Samsung K8P6415UQB n/a 00:10.8 00:13.0 03:33.5 00:13.0 00:13.0 Samsung K9F1G08U0M n/a n/a 02:02.7 n/a 02:02.7 02:02.7 Microchip PIC18LF8720 00:18.7 n/a 00:11.0 n/a 00:11.0 00:11.0 Atmel AT89C51RD2 00:18.0 00:14.4 00:14.4 00:19.2 00:14.4 00:14.4 Downloads Dataman 48UXP Manual (Size: 862.1 KB) Revision 2005 Dataman 48UXP Specification (Size: 164.4 KB) Revision 2005 Dataman 48XP/48UXP Device List (Size: 285.7 KB) Version 9.80 Dataman 48XP/48UXP Software (Size: 7.7 MB) Version 9.80

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	dataman
Country/Region of Manufacture	United States
Model	48UXP
