Datel Dc/dc Converter Bwr-15/500-d5a Output +15 V -15 V Input V 4.7v To 7.5v

US $110

Keokuk, Iowa, United States
Aug 14th

Open on mobile:
QR code

NEW NEVER USED BWR-15/500-D5A Features Low cost! Highly reliable! Proven SMT-on-pcb construction Qual tested; HALT tested; EMC tested Designed to meet UL/ EN60950, BASIC insulation (48VIN models) mark available (48VIN models) Output voltages: ±5, ±12 or ±15 Volts Ultra-wide input voltage ranges: 4.7-7.5V, 9-36V or 18-75V Small packages, 2" x 2" x 0.45" Industry-standard pinouts Fully isolated, 1500Vdc guaranteed Guaranteed efficiencies to 82% –40 to +100°C operating temperature Modifications and customs for OEM’s For your mid-range power requirements, it’s hard to beat the combination of low cost, proven reliability and outstanding electrical performance offered by the 15-20W, dual-output models of DATEL’s new A-Series DC/DC converters. These highly efficient, rugged converters combine straightforward circuit topologies, the newest components, proven SMT-on-pcb construction methods, and highly repeat- able automatic-assembly techniques. Their superior durability is substantiated by a rigorous in-house qualification program that includes HALT (Highly Accelerated Life Testing). The ultra-wide input voltage ranges of the A-Series duals (4.7-7.5V for "D5A" models, 9-36V for "D12A" models and 18-75V for "D48A" models) make them excel- lent candidates for battery-powered systems or for distributed power architectures. Their ±5, ±12 or ±15 Volt outputs cover virtually all standard applications. These popular power converters are fully isolated (1500Vdc guaranteed) and display excellent line and load regulation (with specs as low as ±0.3% max. for line and ±0.5% max. for load). They are completely I/O protected (input overvoltage shutdown and reverse-polarity protection, output current limiting and overvoltage protection) and contain input (pi type) and output filtering to reduce noise. They require no external components and offer true "plug-and-play" convenience. These extremely reliable, cost-effective power converters are housed in standard 2" x 2" x 0.45" metal packages coated with electrically non-conductive materials. They offer industry-standard pinouts and are ideally suited for high-volume computer, telecom/datacom, instrumentation and ATE applications.

“NEVER USED”

Output Voltage Rating (DC)

+15 V -15 V

Brand

DATEL

MPN

BWR-15/500/D5A

Current Conversion

DC to DC

Nominal Current Rating

500 mA
