Dc 12v/24v/36v 450w H-bridge2 Channel Pwm Motor Driver Module Reversing Brake

US $1200

shenzhen, China
Jun 9th

Open on mobile:
QR code

Features Motor drive module parameters: modular nature:H-bridge DC motor driver module(Suitable for 11-36V DC Motor) Scope:High-power DC motor drive Driving voltage: DC 11-36V Output Current: 15A(Maximum continuous load current 20A) Output Power: max 450W (less than 360W do not need heat sink) Working temperature: 40 ℃ to + 85 ℃ Full load temperature: 45 ℃ Dimensions: 6.6cm × 3.8cm x2.8cm Driver module Product Details: (1) full-bridge driver chip + low-resistance 110A NMOS drive tube to achieve motor brake and reversing. (2) chip operating frequency up to 1MHZ, solve VNH3SP30 MC33886 motor noise and heat problems Japan (3) 2 way PWM inputs in 0-100% duty cycle, (4) applies to lithium battery-powered directly drive (5) built-in logic circuit isolation buffer.Support PLC, directly control of various types of 3V or 5V MCU IO ,By analog voltage input to control the motor brake and reversing. (7) chip built-in hardware dead-time control, (8) chip operating frequency up to 1MHZ, Suitable for Empty harbor motordriving EN: enable terminal PWML1: forward rotation Control PWML2: inversion control GND: power grounding cable Outputs: VIN +: driver board power supply input Positive electrode GND: driver board power supply input Negative electrode M +: connect motor wire M-: connect motor wire Control mode instructions: Electricity Level Control: EN = 0 PWML1 = 0 PWML2 = 1 motor forward running EN = 0 PWML1 = 1 PWML2 = 0 motor reverse running EN = 0 PWML1 = 1 PWML2 = 1 motor brake EN = 1 PWML1 = 1 PWML2 = 1 Motor freedom PWM control mode: EN = 0 PWML1 = duty cycle Adjustable PWM signal PWML2 = 1 motor forward running (changing the duty cycle can speed regulation) EN = 0 PWML1 = 1 PWML2 = duty cycle Adjustable PWM signa motor reverse running (changing the duty cycle can speed regulation) EN = 0 PWML1 = 1 PWML2 = 1 motor brake EN = 1 PWML1 = 1 PWML2 = 1 Motor freedom Package Included: 1PCS*DC 12V/24V/36V 450W H-Bridge2 Channel PWM Motor Driver Module Reversing Brake Similar Products 2Pcs L293D L293 Push-Pull Four-Channel Motor Driver IC $0.99 Shipping:Free Time left:4h 30m Stepper Motor Driver Board Module ULN2003 for Arduino 5V 4-phase 5 line 28BYJ48 $0.99 Shipping:Free Time left:25d 5h 3m ULN2003 Stepper Motor Driver Board for Arduino/AVR/ARM $0.99 Shipping:Free Time left:29d 14h 50m NEW EasyDriver Shield stepping Stepper Motor Driver V44 A3967 For Arduino $1.18 Shipping:Free Time left:3d 7h 7m 1PCS L298N ST DUAL FULL BRIDGE MOTOR DRIVER IC ZIP-15 $1.19 Shipping:Free Time left:11d 4h 23m H-bridge Stepper Motor Dual DC Motor Driver Controller Board HG7881 For Arduino $1.42 Shipping:Free Time left:28d 0h 27m A4988 Stepper Motor Driver Module 3D Printer Polulu StepStick RAMPS RepRap $1.43 Shipping:Free Time left:5d 11h 49m SMD IC DRV8825 DRV8825PWPR stepper motor driver Chip Sop-28 Arduino $1.43 Shipping:Free Time left:24d 3h 20m StepStick Stepper motor driver Reprap Prus A4988 A4983 3D Printer driver module $1.44 Shipping:Free Time left:2d 22h 54m H-bridge Stepper Motor Dual DC Motor Driver Controller Board L9110S For Arduino $1.47 Shipping:Free Time left:28d 0h 34m A4988 A4983 3D Printer Driver Module Reprap Prus StepStick Stepper Motor Driver $1.70 Shipping:Free Time left:13d 3h 59m 2PCS ULN2003 Stepper Motor Driver Board Module 5V 12V for Arduino AVR ARM $1.83 Shipping:Free Time left:28d 1h 46m 2PCS Stepper Motor Driver Board Module ULN2003 for Arduino 5V 28BYJ48 Motor $1.86 Shipping:Free Time left:25d 5h 3m DRV8825 stepper motor driver Module arduino 3D printer RAMPS1.4 RepRap StepStick $1.87 Shipping:Free Time left:6d 5h 40m 5Pcs L293D L293 Push-Pull Four-Channel Motor Driver IC $2.25 Shipping:Free Time left:26d 13h 10m TB6560AHQ Stepper motor Driver IC For TOSHIBA ZIP-25 $2.38 Shipping:Free Time left:15d 23h 56m 2PCS L298N ST DUAL FULL BRIDGE MOTOR DRIVER IC ZIP-15 $2.45 Shipping:Free Time left:4d 1h 47m 2Pcs H-bridge Stepper Motor Dual DC Motor Driver Controller Board L9110S $2.47 Shipping:Free Time left:5h 44m 2PCS EasyDriver Shield stepping Stepper Motor Driver V44 A3967 For Arduino Good $2.58 Shipping:Free Time left:3d 7h 7m A3977 A3977SEDT A3977SED Microstepping DMOS Motor Driver $2.67 Shipping:Free Time left:1d 6h 16m 2Pcs H-bridge Stepper Motor Dual DC Motor Driver Controller Board HG7881 new $2.77 Shipping:Free Time left:20d 2h 26m 2pcs SMD IC DRV8825 DRV8825PWPR stepper motor driver Chip Sop-28 Arduino $2.89 Shipping:Free Time left:24d 3h 20m 5PCS ULN2003 Stepper Motor Driver Board Module 5V 12V for Arduino AVR ARM $2.93 Shipping:Free Time left:28d 1h 46m 2PCS A4988 Stepper Motor Driver Module 3D Printer Polulu StepStick RAMPS RepRap $3.06 Shipping:Free Time left:5d 11h 33m 2PCS StepStick Stepper motor driver Reprap Prus A4988 3D Printer driver module $3.16 Shipping:Free Time left:2d 23h 5m Hot TB6612FNG Dual Motor Driver Module for Arduino STM32 ARM Replce L298N $3.45 Shipping:Free Time left:24d 1h 21m 10Pcs L293D L293 Push-Pull Four-Channel Motor Driver IC $3.78 Shipping:Free Time left:26d 13h 12m 5PCS Stepper Motor Driver Board Module ULN2003 for Arduino 5V 28BYJ48 Motor $3.96 Shipping:Free Time left:25d 5h 3m I2C IIC control H-Bridge DC Motor Driver Moto Shield DRV8830 Module For Arduino $3.96 Shipping:Free Time left:25d 5h 40m 2PCS DRV8825 stepper motor driver Module arduino 3D printer RepRap 1.4 StepStick $4.04 Shipping:Free Time left:6d 5h 39m Dual Channel Motor Driver Shield L298P DC Stepper Driver Board For Arduino AL $4.23 Shipping:Free Time left:27d 5h 59m 2PCS A3977 A3977SEDT A3977SED Microstepping DMOS Motor Driver $4.57 Shipping:Free Time left:1d 6h 16m Mini VNH2SP30 Stepper Motor Driver Monster Moto Shield module 30A For Arduino $4.59 Shipping:Free Time left:19d 1h 20m ORIGINAL TOSHIBA TB6600HG ZIP-25 Stepper Motor Driver controller IC $4.70 Shipping:Free Time left:2d 5h 41m High Current MOSFET Switch Module DC Fan Motor LED Strip Driver Steples NEW $4.77 Shipping:Free Time left:6d 12h 21m DRV8825/A4988 3D Printer Stepper Motor Driver Control Extension Boards $4.84 Shipping:Free Time left:22d 5h 53m 2PCS A4988 A4983 3D Printer Driver Module Reprap StepStick Stepper Motor Driver $4.90 Shipping:Free Time left:25d 3h 26m 5PCS L298N ST DUAL FULL BRIDGE MOTOR DRIVER IC ZIP-15 $4.96 Shipping:Free Time left:11d 4h 23m L298P Shield R3 DC Motor Driver Module 2A H-Bridge 2 way For Arduino UNO 2560 NW $5.44 Shipping:Free Time left:27d 4h 4m 2Pcs TB6560AHQ Stepper motor Driver IC For TOSHIBA ZIP-25 $5.52 Shipping:Free Time left:15d 23h 55m Dual channel Motor Driver Shield L298P DC stepper motor driver board for Arduino $5.53 Shipping:Free Time left:27d 4h 5m Stepper Motor Driver Controller Shield and StepStick Driver A4988 for 3D printer $5.90 Shipping:Free Time left:28d 3h 31m 5 axis CNC Breakout Board with optical coupler For Stepper Motor Driver MACH3 CZ $6.09 Shipping:Free Time left:13d 4h 57m 5PCS EasyDriver Shield stepping Stepper Motor Driver V44 A3967 For Arduino Good $6.11 Shipping:Free Time left:3d 7h 7m 5Pcs H-bridge Stepper Motor Dual DC Motor Driver Controller Board L9110S $6.47 Shipping:Free Time left:1d 5h 2m 5Pcs H-bridge Stepper Motor Dual DC Motor Driver Controller Board HG7881 new $6.47 Shipping:Free Time left:20d 2h 25m 5PCS A4988 Stepper Motor Driver Module 3D Printer Polulu StepStick RAMPS RepRap $6.50 Shipping:Free Time left:5d 11h 25m TB6560 Driver Board CNC Router Single 1 Axis Controller Stepper Motor Drivers 3A $6.50 Shipping:Free Time left:18d 2h 27m Shipping & Handling Shipping Time: The items you ordered will be shipped out in 1-2 business day by Hong Kong Post Air Mail when your payment is clear. Payment We accept PayPal only. We only ship item to your PayPal verified address. Payment must be received within 5 Days from the date of purchase. Return Policy All the products we are selling include factory warranty, don’t cover items that have been abused, burned and damaged in any form. Please contact us via eBay Message if you have NOT received item in 30 days, we will check it with post office, and then resend or refund any missing item. In the unlikely event that your product is faulty in anyway, you must contact us ASAP and then return it within 7 Days of receipt. The postage and packaging fee will NOT be refunded. We will not be responsible for the delivery or insurance charges incurred in returning item back to us. If you return an item purchased from us, it must be back in Factory Condition. This includes packaging, inserts, manuals etc. Please allow up to 5 Working Days for us to process your returned item. Feedback & Contact Us We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative feedback without asking for help.We will try our best to solve any problem. If you have any questions, please feel free to contact us by ebay message. We will reply you within 48 Hours. On Oct-10-15 at 09:07:35 PDT, seller added the following information:
