Dc 12v 24v Stepper Motor Pulse Signal Generator Module For Stepper Motor Driveu1

US $10.21

  • Shenzhen, China
  • Aug 2nd
DC 12V 24V Stepper Motor Pulse Signal Generator Module for Stepper Motor DriveU1 1.this module is a pulse generation module, supply the control signal to stepper driver.To control the stepper motor, it must be equipped with a drive. 2.this simple controller + stepper motor + stepper motor + DC power supply can be composed of a simple set of control platform. 3.the controller has high 5.4k-160khz, middle 540-16.6khz, low 80-2.4khz total of 3 kinds of low frequency signal can be used to select the jumper. 4.can produce pulse signal, can also produce PWM signal, can choose the jumper. 5.the frequency of measurement: PUL and common cathode end. EN=ENA=FREE Enable PUL=PULS=CLK Pulse DIR=CW=CWW Direction Common anode Connection method (B) EN+ PUL+ DIR+ connect together to com+. EN- connect EN PUL- connect CLK DIR- connect DIR colour:black material:PCB Package Contents: 1 x Pulse Signal Generator to Stepper Motor Driver Module
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
MPN Does Not Apply
Model Regular
Brand Unbrand
Custom Bundle Regular
Marke SODIAL
Bundle Description No
Hersteller SODIAL
Modified Item NO
Power Source Regular
Modification Description No
Enclosure Universal
Maximum Amperage Universal
Country/Region of Manufacture China
Rated Load Universal
Unit Quantity Universal
Voltage Universal
UPC 4894805490205
ISBN 4894805490205
EAN 4894805490205
