Dc 3-18v Kda2 Single Key Bistable Switch Circuit Module 2-channel Output Npn

US $3800

shenzhen, China
Oct 22nd

Open on mobile:
QR code

New Arrivals Modules Home Gadgets Fishing Outdoor Product Picture Gallery Power Module Wireless Modules Sensor DIY LED Board Development Board Function Modules Digital Voltmeter Description DC 3-18V KDA2 Single Key Bistable Switch Circuit Module 2-Channel Output NPN Product Introduction: 1.If key time is less than 0.5s,control No.1 channel output port on/off,press once on,press again off;then cycle 2.If key time is more than 0.5s,control No.2 channel output port on/off,press once on,press again off;then cycle 3.Power Voltage:DC 3V-18V 4.Standby Current:2uA 5.Output Driving Type:NPN 6.Output Driving Capacity:1500mA/channel 7.Trigger Type:negative trigger 8.Applications:output port has protection diode,can directly connect with relay Pin Definition: 1.VCC:power positive 2.VO1:output port 1 3.VO2:output port 2 4.TG:trigger port 5.GND:power negative After power on,to set initial output state Short circuit setting point 1-3 are all disconnected;after power on,2-channel output are all off 1.Short circuit setting point 1 connected:power on state is 1 on 2 off 2.Short circuit setting point 2 connected:power on state is 1 off 2 on 3.Short circuit setting point 1-2 both connected:after power on,2-channel output are on 4.Short circuit setting point 3 connected:off memory function;after power on,output remains state before power off;at this time,setting point 1-2 do not work Shippment Payment Return Policy Feedback About us We will arrange shipping for you within 24 Hours after payment cleared except the holidays. We only ship to the confirmed address provided by PayPal. Before you pay, please make sure your address in PayPal matches the address you would like us to ship to. If not, please let us know before we sent you the package, or we will not be responsible for any loss. hope you could understand. -We ship items to Worldwide. Thank you! -we will ship out the order in 1-2 business days after payment cleared .Since it is international shipping ,delivery time is about 15--28 business days to arrive to most countries. We accept Paypal ONLY. It is easy and safe for you to pay by credit cards, debit cards, bank transfers and PayPal account balances. * We believe our items are so outstanding. We are convinced you will be happy with your Purchase. * If you do not satisfy with our items. Please simply return to us within 30 Days in original condition. Just pay for the returned postage. Then we can issue full refund to you after the returned item arrived at our warehouse. * Please include your eBay ID and item number with any email requests. * When you satisfied with our product and services please leave us positive feedback. * If you have got the package, please confirm "Delivery on time" For us. * If a problem occurs, contact us immediately with any email request. * Just contact us using the " Ask the seller a question" link on eBay. We mainly sell Modules, IC Acccesories, Home Gadgets, and outdoor products. Almost all products you need, You can get a best price once you send us the ebay message. For bulk order or wholesale, we promise to offer you a very competitive price! We welcome do more pleasant business with you. SKYPE: ada-yu2013 inkfrog terapeak inkFrog Analytics On Oct-21-16 at 14:23:07 PDT, seller added the following information:
