Dc 5v Stepper Step Motor + Driver Test Module Board Uln2003 For Arduino

US $170

Shenzhen,Guangdong, China
Mar 4th

Open on mobile:
QR code

Product description: 1,Standard double panel design,fine workmanship, board size:38mm X 30mm 2, Use ULN2003 drive chip,500mA 3,In stepping motor port,four channels highlight SMD green LED diode indicates working status 4, In DC motor port,one channel highlight SMD green LED diode indicates working status 5, Power light:highlight red SMD LED diode 6, Equipped with stepping motor standard interface and DC motor standard interface,can directly call waiting when using 7,Choose through red short circuit hat,support different working voltage motors connect short circuit hat,choose 5V as the working voltage for steeping motor/DC motor Take off short circuit hat,steeping motor/DC motor can choose external voltage for power supply through pins Wiring method: The wiring method for stepping motor: Left 1 N 1 ~ 1 N 4 connect to the four corresponding IO wires of MCU The right black pins are defined from top to VCC,A,B,C,D ( connect to the concentric line,phase A,B,C,D of stepping motor)s The wiring method for DC motor: Left 1 N1 ~ 1 N 4 connect correspondingly to the four IO wires of MCU The right black pins are defined as:below is VCC Power supply method: Connect short circuit hat,choose 5V as the working voltage for stepping motor/DC motor Take off short circuit hat,stepping motor/DC motor can choose external voltage for power supply via pins Speed down stepping motor Diameter:28mm Voltage:5V Stepping angle:5.625 X 1/64 Speed reduction ratio:1/64 Five lines four phases,can be driven by common uln2003,can be used as connecting two phase;can be used with PCB board,direct plug and socket,easy to use on PCB board Shipping list 1,ULN2003A stepping motor driving board(as shown in picture),all welded and tested 2, 5V, four phases five lines stepping motor,brand new stepping motor/speed down motor 288YJ-48-5V ICA109 Material_Download Payment Policy We only accept PAYPAL.Payment must be received within 5 days of the auction close. We reserve the right to cancel the transaction and relist the item if payment has not been received within this time frame. Shipping Policy For international orders, we are not responsible for any charges, taxes, fees or delays imposed on you by your Country's Customs Department.Most orders ship within 1 business days of receiving cleared payment (excluding holidays and weekends).If this is your first deal with us or buying for an item which needs international shipping, we suggest you review our shipping terms in descriptions. International shipping usually takes longer time than domestic, since it’s based on shipping service provider and both countries Customs.Estimated delivery time varies by destination but usually take 20-30 business days(excluding holidays and weekends),or longer for certain countries. It depends on the cleared payment and your local post office process. Feedback We offer FREE SHIPPING.POSITIVE FEEDBACK WITH AN OVERALL 5 DETAILED SELLING RATING(DSR), which means CRITICAL for us – a new but studious team on eBay, your great comments will lead us to get more potential customers, and make us more confident to develop business and serve you better.If there is ANY dissatisfaction, don't hesitate contacting us via ebay message We will meet your need by all means available. Return Policy Upon receipt of your item, if you are not completely satisfied please contact me via e-mail immediately. * You may return the item within 14 days from the date you received it. * I will refund the total amount you paid or you may choose an item of equal value from one of my auctions or from my store. On Aug-08-14 at 01:19:08 PDT, seller added the following information:
