DC/AC Oscilloscope Current Probe 50MHz Dual Range 5A/30Arms Peak 50A 1X 10X, US $1,760.00 – Picture 0
DC/AC Oscilloscope Current Probe 50MHz Dual Range 5A/30Arms Peak 50A 1X 10X, US $1,760.00 – Picture 0

Dc/ac Oscilloscope Current Probe 50mhz Dual Range 5a/30arms Peak 50a 1x 10x

US $1,760.00

  • Shenzhen, China
  • Jun 9th
Open on mobile:
QR code
CP8030B(30A/50MHz Double range selection)   1. Bandwidth (-3dB) DC-50MHz 2. Rise time 7ns or less 3. Maximum continuous current 30Arms 4. The peak current 50A 5. Power supply mode DC 12V/1.2A   Summary The CP8000A series uses a combination of Hall effect and transformer technology which enables measurements to be made on DC, AC and impulse currents. It’s key features include highly accurate current measurements?wide bandwidth?easy current measurements?DC/AC measure?over-current protected and indication(buzzer and LED indicator)?double ranges selection?low current measurements?degauss and auto zero function. CP8030B has a 50 MHz bandwidth and is designed to measure continuous currents up to 30 Amp.   Key features 1. Highly accurate current measurements 2. Easy current measurements 3. Wide bandwidth 4. DC/AC measure 5. Over-current protected   Application 1. Switching power supply 2. LED lighting design 3. Semiconductor Devices design 4. Inverter/ transformer design 5. Electronic ballast design 6. Engine driven design 7. Electric vehicle design   Parameter CP8030B   BW(-3dB) DC-50MHz(see Fig.1)   Rise time 7ns or less   Continuous maximum input range 30Arms (Frequency derating see Fig.2)   Max peak current value 50A   Range 5A 1X        30A       10X   Over 5A >=5A        30A       >=50A   Current Transfer Ratio 5A 1V/A 30A 0.1V/A Lowest Measurable Current 5A 1mA 30A 10mA Amplitude accuracy (DC,45-66Hz ) 5A ±1%±1mA 30A ±1%±10mA Input impedance see Fig.3 Power Supply DC 12V/1.2A Safety standards IEC61010-1: 2010 IEC61010-2-32: 2012 EN61010-1: 2010 EN61010-2-32: 2012 Max. rated voltage to earth 300V CAT I
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Model CP8030B
Country/Region of Manufacture China
MPN CP8030B
Brand generic
UPC Does not apply
