Dc Auto Boost&buck Converter 5-32v To 1.2-35v Volt Step Up/down Xl6009 Regulator

US $4.79

GuangZhou, China
Jun 9th

Open on mobile:
QR code

DC-DC Auto Boost&Buck Module 5-32V To 1.2-35V Volt Step Up/Down Converter XL6009 Description 1.Brand new original XLSEMI chip 2.SMD electrolytic capacitors 3.Up to 400Khz operating frequency, and LC filter circuit, output ripple is very low. 4.TDK inductance make the heat and noise to a minimum. 5.Input and output three MLCC Multilayer ceramic capacitors, anti-interference and enhance stability. 6.Built-in MOSFET,can up to 94% efficiency. 6.Increased enabled port, you can control whether the booster circuit is working. Features: Module properties: non-isolated boost buck module Input voltage:5-32V Output voltage:1.2-35V continuously adjustable Input current:4A(max) Output current:1.5A(max) Output power:20W(natural cooling) Maximum output power = input voltage * 4A * conversion efficiency Conversion efficiency:Commonly measured voltage and current efficiency (the following is for reference) Input voltage/V Input current/A Output voltage/V Output current/A conversion efficiency 1 5.083 0.531 12.012 0.200 89.01% 2 5.055 1.361 12.006 0.500 87.25% 3 5.011 2.990 11.983 1.000 79.98% 4 8.413 0.316 12.021 0.200 90.43% 5 8.402 0.777 12.016 0.500 92.03% 6 8.378 1.585 12.004 1.000 90.40% 7 8.355 2.440 11.986 1.500 88.19% 8 8.332 3.345 11.953 2.000 85.78% 9 12.012 0.442 24.125 0.200 90.88% 10 11.993 1.093 24.125 0.500 92.02% 11 11.963 2.227 24.050 1.000 90.27% 12 11.985 1.352 36.320 0.400 89.66% 13 23.985 1.087 48.020 0.500 92.09% 14 23.992 0.799 35.850 0.500 93.51% Operating temperature: Industrial grade (-40 ℃ to + 85 ℃) Full load temperature rise: 45 ℃ Operating frequency: 400khz No-load current: Typical 15mA (5V turn 12V) Load regulation: ± 0.5% Voltage regulation: ± 0.5% Dynamic response speed: 5% 200uS Enable Control Port: Yes, high level 1.4V-VIN (ON), low level 0-0.8V (OFF), the default high level Short circuit protection: None (Please install fuse or protection circuit input) Input reverse polarity protection: None, please with our reverse protection diode board or in the input series. Installation: You can screw fixation(fixing holes 3 mm), 2 fixing holes Connection: welding,add pin can be soldered directly to the PCB Note:This module without PBCA shell. Package Included: 1 x DC-DC Boost&Buck Adjustable Module XL6009 Payment We only accept PayPal. Payment must be made within 7 calendar days of the auction end time. We reserve the right to cancel your order if the payment is not made within 7 calendar days of checkout. We will use your Ebay/Paypal shipping address as the delivery address. Please make sure to provide us with correct and detailed shipping address. To Russia, please the receiver name must write your full name as post office required. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Shipping Detail All the items to USA will ship via ePacket with tracking number. To UK and Australia the buyer can choose "Expedited Int'l Shipping", we also will ship via ePacket with tracking number, it is better than registered mail,usually delivery time is 7-20 business day. But to Australia ZIP code 2898/2899/6798/6799/7151 can NOT ship via ePacket. Other countries, total price below $30 we will ship your item without tracking number. Otherwise, if you need Registered Mail shipping, please add $2.5(Can choose "Standard Int'l Shipping",we will ship via registered mail). Usually all the items will be shipped via Hong Kong Post Airmail or China Post Airmail. If you need the other express way(EMS/DHL/FedEx/UPS),please contact with us for the correct price. Your order will be dispatched within 2 business days after the full payment is cleared. Airmail Packets' Delivery Time(reference only): USA,Australia,New Zealand,Southeast Asia, East Asia. 7-20 business days. Most European countries (France,Spain,Germany,UK,Sweden, Norway, Denmark,Netherlands,Austria,Portugal, Croatia, Finland, Switzerland, etc.) ,Canada,10-25 business days. Some remote city will take more than 25 business day. Italy,Russia, Brazil, Turkey, Ukraine, India, 14-35 business days, 90% take long time. Eastern Europe,West Asia,Central Asia, 15-30 business days,80% take long time. Africa,Chile,Argentina,Mexico,Other Countries. 15-40 business days,usually long time. Delivery time depends on postal process and other factors(Weather,Vacation,Customs,etc.),it can receive as fast as 7 days,but it can take as long as 4-7 weeks in some cases. If you do not get your item in reference delivery time, please contact us first through ebay message (Please do NOT open any case), we will reply you as soon as possible(within 24 business hours). Return Policy Please contact us before you leave Negative or Neutral Feedback if you are not satisfied with our products,we will resolve it asap. DOA(Dead On Arrival) or Wrong Item will be offered exchange. Refund will be offered if stock is not available Defective goods must be returned within 30 days after receiving it for exchange or refund. Buyer is responsible for return shipping cost in any situations. Contact us Please feel free to contact us from ebay if you have any questions , we will reply you within 48 hours except the weekends and public holidays. Please contact with us before you leaving Negative or Neutral feedback, and please DO NOT open any case, we will try my best to resolve your problems ASAP.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country of Manufacture	China
Model	Voltage step up/down converter
Input voltage	DC5V-32V
Brand	Generic
Output voltage	DC1.2V-35V
MPN	Does not apply
UPC	Does not apply
