Dc Constant Current 3a Power Voltage Converter I.5 -30v Led Driver Charger

US $31

Nanjing , Jiangsu, China
Jan 29th

Open on mobile:
QR code

Feature Module parameters: Properties: non-isolated step-down constant current, constant voltage module (CC CV) charging module Scope: High-power constant current LED driver, battery charger (including ferroelectric), 4V, 6V, 12V, 14V, 24V battery charging, nickel-cadmium nickel-metal hydride batteries (battery) charger, solar panels, wind turbines Input voltage: 7-35V, Output voltage: 1.25-30V adjustable Output Current: 3A (more than 15W, please install heat sink, this item do not include HEAT SINK) Constant current range :0-3A (adjustable) revolving light current: constant current value * (0.1), such as the constant current value is 3A, revolving light current is set to constant current of 0.1 times (0.1 * 3A = 0.3A), when adjusted constant current value to 2A, then revolving light current is constant current of 0.1 times (0.1 * 2A = 0.2A). this version is 0.1 times fixed Feature: Dropout voltage: 2V Output power: natural cooling 15W, 25W with heat sink Conversion efficiency: 90% (up to 90% (the higher the output voltage, the higher the efficiency) Output ripple: 20M bandwidth (for reference) Input 12V Output 5V 3A 60mV (MAX) Operating Temperature: Industrial (-40 °C to +85 °C) (ambient temperature exceeds 40 °C, lower power use, or to enhance heat dissipation) Full load temperature rise: 45 °C No-load current: Typical 10mA (12V switch 4.2V) Load regulation: ± 1% Voltage regulation: ± 0.5% Constant accuracy and temperature: the actual test, the module temperature changes from 20 °C to 100 °C, less than 1% change constant current value (constant current value 1A) Dynamic response speed: 5% 200uS Potentiometer adjustment direction: clockwise (increase), counterclockwise (decrease), potentiometer close to the input is Voltage regulation (CV), potentiometer close to the output is current regulate (CC), Indicator: two-color LED charging indicator light red, fully charged light green (do not connect load light green) Output short circuit protection: Yes, constant current (constant current setting values) Input reverse polarity protection: Yes, Output to prevent reflux: Yes, the output has an internal series a diode to prevent reflux. Connection: Welding, plus pin can be directly soldered to a PCB Battery Charging method: 1. Make sure the recharge battery float voltage and charge current, input voltage of the module. 2. adjust constant voltage regulator, the output voltage about 5V. 3. With a multimeter ( to 10A) Measuring output Short-circuit current, Also adjust the constant regulator allows Output current reaches a predetermined charge current value; 4. Adjust Constant regulator allows Output voltage reaches the float voltage; 5. connected to the battery, try charging. (1,2,3,4 step input connect power, output do not connect battery.) LED constant current driver Usage: 1. Make sure LED current and the maximum operating voltage; 2. adjust constant voltage regulator, the output voltage about 5V. 3. With a multimeter ( to 10A) Measuring output Short-circuit current, Also adjust the constant regulator allows Output current reaches a predetermined LED working current value; 4. Adjust Constant regulator allows Output voltage Reach LED maximum working voltage; 5. Connected to the LED, test. (1,2,3,4 take steps input connect power, output do not connected LED.) Package DC-DC voltage converter module X 1pcs WELCOME TO MY EBAY STORE http://stores.ebay.com/skt-flyer Thanks a lot for your attention! :) We aim to provide high quality products and a greater service to you and a five'' stars* rating from you for each and every transaction is welcome. Thanks a lot. :) If you are not 100% satisfied,PLEASE don't leave a neutral or negative but contact us First so that we can help you. Please feel free to contact us if you have any questions. :) Payment We accept payment by Paypal. Shipping We ship by Airmail. We will select the fast and reliable way for delivery. Save on shipping and safter on delivery. We are not responsible for wrong or undeliverable address. Tracking number: The price is USD2.00, it is optional but you are recommanded to use it. Please contact us to buy if you need it. Delivery time By airmail: 2-4 weeks to ASIA, West EURO, and North America. 3-5 weeks to South America, Mid-East, East EURO and Africa. Over 45 days to Russion , italy By EMS: 5-7 businessdays For more information about the shipping time and please refer to the following link: http://members.ebay.com/ws/eBayISAPI.dll?ViewUserPage&userid=skt_flyer For public holiday in China and the delivery time will be delayed for some days due to the post office and customs will have holiday and the process of the package will be delayed. International Buyer please note 1 We are not responsible for any custom duty or import tax.These charges are not included in the item price and shipping cost. 2 Please Check with your country's customs office to determine what these additional costs will be prior to bidding/ buying. Return If you are not satisfied when you receive your item, please return it within 7 days for a replacement or money back. Please contact me before you return it. Not accept returning of electronic components. Full refund after we receive our original item.

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

Country of Manufacture

China
