Dc-dc Adjustable Boost Module 3~35v Up3.5~35v100w Digital Display Voltmeter

US $200

Shenzhen, China
Jun 22nd

Open on mobile:
QR code

DC-DC Adjustable Boost module 3~35V up3.5~35V100W digital display voltmeter Description Introduction Show some use more advanced voltmeter microprocessor, the boost section using imported boost U.S. Controller, by utilizing the power MOSFT on-resistance and eliminating the current sense resistor, the maximum Improve efficiency, efficiency up to 96.4%. Imported high-power low-impedance MOS pipe, large package, high current High efficiency Schottky, wide thick PCB traces, high-efficiency and low temperature rise is guaranteed. Wide power Pressure of work, when the input and output voltages are 20V up to 128W output power above. Long-life open High-frequency switching power supply special high-capacity low-impedance (low ESR) electrolytic capacitors, so that lower output ripple. Module Chip are imported, material + feet, stable performance. Double combination correction voltage method The output side of the correction: Step 1, Power On, Right to adjust the voltage meter to display the output side of the state, right-2S press release, the voltage Tables and output voltage lights flashing and display the current voltage value, enter the correct voltage calibration status: Step 2 Tap the right button to increase the voltage value, touch the button on the left to reduce the voltage value. Step 3 After you are finished, press the right button 2S, release the button to exit the calibration mode, enter positive Display mode, all parameters set to automatically power down to save. Input side correction: Correction similar to the output side, in the state table shows the input voltage into the voltage, the step above. The product to mass production, each module before shipment after three or more detectionand you can use. Performance parameters: I, Input voltage: 3 - 35V DC (Note: Input voltage is less than 4V, onboard voltmeter failure " 2, Input Current: 9A (max) 3, the output voltage: 3.5-35V DC (This board is a step-up board, taking the voltage to> = input voltage) 4, the output current: 6A (max) 5, the output power:. 75W (when the input voltage is greater than 20V output can reach 128W) 6, conversion efficiency: 96.7% (maximum) 7, the output ripple: 24mV (TYP) 8, onboard voltmeter range :4-40V, error 0. 1V 9, short-circuit protection: Yes (limited current 14A) 10, input reverse polarity protection: None (If necessary, please enter the string into the high current diode) 11, length x width x height = 67 * 43 * 12MM (excluding pillars) Tips: When access high-power load by dry just machines Assembly limiting the inrush current is to build self-locking protection. Conference the first boot, and then access the load shipping list:1pcs DC-DC Adjustable Boost module 3~35V up3.5~35V100W digital display voltmeter Payment We accept Paypal as the payment method. Shipping Free Shipping with Tracking Number!!! Every mail we post have a Tracking Number to check "where is my mail? How long i can get the goods!" The default shipping is by E-PACKET ( USPS )(7-12 working days) Item will be shipped within 2-3 working days after full payment is received. The delivery to most of the countries will take 1-2 weeks(7-12 working days) , if there's no problem when pass through the customs. We only ship to the approved address given in PayPal payment. Please make sure payment address in PayPal is correct. Any non-received items caused by invalid address registered on PayPal are not in our full refund or replacement policy. Terms of Sale If you can't receive the product within 2 months (60 days), please contact with us,we promise to payback 100% of your money. We ensure our products work normally before post.If the products is broken before arrival to you,all you should do is taking a photo to show us our broken product.We promise to payback 100% of your money!!! About Us My Dear Friend! Welcome to my store!We are in the biggest market of Electronic Component!We will be the best friend with your Electronic diy!!!Thank you very much!!! Contact Us Welcome to travel to China ShenZhen!We can take you to the biggest market of Electronic Component and Play in ShenZhen! You can cantact us on ebay! We will Reply you in 24 hours!
