Dc/dc Buck Converter 5a Cc Cv 6-36v To 1.25v-32v Mppt Step-down Solar Controller

US $8.79

GuangZhou, China
Jun 9th

Open on mobile:
QR code

DC/DC Buck Converter 5A CC CV 6-36V To 1.25V-32V MPPT Step-down Solar Controller Description Module Name: MPPT 5A Step-down Module Constant Voltage Constant Current Module Properties: Non-isolated buck module (BUCK) Input voltage: 6-36V Output voltage:1.25-32V continuously adjustable (the default output 5V) MPPT voltage setting range: 6-36V Output current range: 0.05-5A (The default output current is 3A,within 3A for a long time) Turn lights output range: 0.01-5A (default 0.3A) the current range will be a little difference because the parts parameter error. Multifunctional double display: input voltage, output voltage, output current, output power Operating temperature: -40 to + 85 degrees Operating frequency: 180KHz Conversion efficiency: up to 95% (efficiency is related with input voltate,output voltage,current and voltage difference) Short circuit protection: Yes Over temperature protection:Yes (automatically shut off the output after overtemperature) Input reverse polarity protection: None, (if necessary, please add the string into the diode) Output anti-irrigation protection: None, the output must be connected to the battery plus blocking diode, otherwise it will burn the module! Charging indicator:charging red, fully charged green. Turn light detection way for current.When using solar panels to supply electricity,the small sun charge current is also very small, less than turn light's current, it will green light,but it is not full, please note that distinction. Installation: 3mm screws(4) Connection:Terminals, IN is input, OUT is output Size:60*31*22 mm(L * W * H) Note: The current detection module is the low-end testing, please do not directly connect the input negative with the output negative! Applications: 1.DIY is a voltage Regulator, with constant current function, Short-circuit protection, can protect the load. 2.The power supply for your electronic equipment. 3.For a variety of battery charge,with Charging indicator, can easily observe the state of charge. 4.Charge for all kinds of batteries, with MPPT function, can enhance the charging current to double. With a constant current and prevents battery overcharge, effective protection of the battery. 5.It can support high-power LED. 6.As a car power supply , it can for your cell phone or digital products supply. Adjust voltage, current and turn lights method will send by email if you need, please contact us. Package included: 1 x MPPT Solar Controller DC buck converter 5A Payment We only accept PayPal. Payment must be made within 7 calendar days of the auction end time. We reserve the right to cancel your order if the payment is not made within 7 calendar days of checkout. We will use your Ebay/Paypal shipping address as the delivery address. Please make sure to provide us with correct and detailed shipping address. To Russia, please the receiver name must write your full name as post office required. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Shipping Detail All the items to USA will ship via ePacket with tracking number. To UK and Australia the buyer can choose "Expedited Int'l Shipping", we also will ship via ePacket with tracking number, it is better than registered mail,usually delivery time is 7-20 business day. But to Australia ZIP code 2898/2899/6798/6799/7151 can NOT ship via ePacket. Other countries, total price below $30 we will ship your item without tracking number. Otherwise, if you need Registered Mail shipping, please add $2.5(Can choose "Standard Int'l Shipping",we will ship via registered mail). Usually all the items will be shipped via Hong Kong Post Airmail or China Post Airmail. If you need the other express way(EMS/DHL/FedEx/UPS),please contact with us for the correct price. Your order will be dispatched within 2 business days after the full payment is cleared. Airmail Packets' Delivery Time(reference only): USA,Australia,New Zealand,Southeast Asia, East Asia. 7-20 business days. Most European countries (France,Spain,Germany,UK,Sweden, Norway, Denmark,Netherlands,Austria,Portugal, Croatia, Finland, Switzerland, etc.) ,Canada,10-25 business days. Some remote city will take more than 25 business day. Italy,Russia, Brazil, Turkey, Ukraine, India, 14-35 business days, 90% take long time. Eastern Europe,West Asia,Central Asia, 15-30 business days,80% take long time. Africa,Chile,Argentina,Mexico,Other Countries. 15-40 business days,usually long time. Delivery time depends on postal process and other factors(Weather,Vacation,Customs,etc.),it can receive as fast as 7 days,but it can take as long as 4-7 weeks in some cases. If you do not get your item in reference delivery time, please contact us first through ebay message (Please do NOT open any case), we will reply you as soon as possible(within 24 business hours). Return Policy Please contact us before you leave Negative or Neutral Feedback if you are not satisfied with our products,we will resolve it asap. DOA(Dead On Arrival) or Wrong Item will be offered exchange. Refund will be offered if stock is not available Defective goods must be returned within 30 days after receiving it for exchange or refund. Buyer is responsible for return shipping cost in any situations. Contact us Please feel free to contact us from ebay if you have any questions , we will reply you within 48 hours except the weekends and public holidays. Please contact with us before you leaving Negative or Neutral feedback, and please DO NOT open any case, we will try my best to resolve your problems ASAP.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country of Manufacture	China
Output current	5A
Input voltage	6V-36V
Model	Voltage step down converter
Output voltage	1.25V-32V
UPC	Does not apply
