Dc-dc Buck Converter 7-35v To 1.25-30v 15w Cc/cv Power Supply Module Lm2596

US $91

GuangZhou, China
Jan 29th

Open on mobile:
QR code

DC-DC Buck Converter 7-35V to 1.25-30V 15W CC/CV Module For LED Drive&Charging Description Applications: High Power LED constant current Driver, Lithium battery (including ferroelectric) Charging, 4V?6V?12V?14V?24V battery charging, Nickel cadmium nickel hydrogen battery charging, Solar panels, Wind turbines. Features: Module Properties: non-isolated step-down constant current, constant voltage module (CC CV) charging module Input voltage:7-35V Output voltage:1.25-30V(Continuously adjustable) Output current:Max 3A(high than 15W need heat sink) Constant current range:0-3A(Adjustable) Transfers lamp electric current:Constant current value * 0.1. The lowest voltage difference:2V Output power: natural cooling 15W, add heat sink 25W. Conversion efficiency:Max 90%(the higher output voltage,the higher efficiency) Output ripple:20M bandwidth (only for reference) Input 12V output 5V 3A 60mV(MAX) Operating temperature: Industrial (-40 ℃ to +85 ℃) (ambient temperature exceeds 40 degrees, lower power use, or to enhance heat dissipation) Full load temperature rise:45℃ No-load current: typical 10mA(12V to 4.2V) Load regulation:±1% Voltage Regulation:±0.5% Constant current accuracy and temperature:The actual test, the module temperature changes from 20 degrees to 100 degrees, the constant current value varies by less than 1% (constant value 1A) Dynamic response speed:5% 200uS Potentiometer adjustment direction: clockwise (increase), counterclockwise (decrease) near the potentiometer input is a voltage regulator (CV), near the potentiometer output is a current regulator (CC). Indicator: two-color indicator, when charging indicator is red, charging is completed indicator is green(no load connect then the indicator is green). Output short circuit protection:Yes,Constant current value. Input reverse polarity protection:Yes. Output backflow prevention:Yes.Series connection backflow prevention diode in internal. Wiring: Welding,Plus pin can be directly soldered to the PCB. Size:49(L)*23.4(W)*11.4(H) mm(Exclude potentiometer) Battery charging method: You need to Confirm the battery float voltage and charging current, the input voltage of the module. Adjust the constant voltage potentiometer, the output voltage adjust to about 5V. Use multimeter 10A measuring the output short-circuit current,then adjust the constant current potentiometer to make the output current reaches a predetermined charge current value. Adjust the constant voltage potentiometer to make the output voltage reaches the float voltage. Connected to the battery, try to charge (1, 2, 3, 4 steps for the module input power, output no-load is not connected to the battery) LED constant current drive method: You need to Confirm LED drive working current and maximum operating voltage. Adjust the constant voltage potentiometer, the output voltage adjust to about 5V. Use multimeter 10A measuring the output short-circuit current,then adjust the constant current potentiometer to make the output current reaches LED working current. Adjust the constant voltage potentiometer to make the output voltage reaches LED maximum operating voltage. Connect LED,Try. (1, 2, 3, 4 steps for the module input power, output no-load is not connected to the LED lights) Package included: 1 x LM2596 DC-DC Buck Converter Module Payment We only accept PayPal. Payment must be made within 7 calendar days of the auction end time. We reserve the right to cancel your order if the payment is not made within 7 calendar days of checkout. We will use your Ebay/Paypal shipping address as the delivery address. Please make sure to provide us with correct and detailed shipping address. To Russia, please the receiver name must write your full name as post office required. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Shipping Detail All the items to USA will ship via ePacket with tracking number. To UK and Australia the buyer can choose "Expedited Int'l Shipping", we also will ship via ePacket with tracking number, it is better than registered mail,usually delivery time is 7-20 business day. But to Australia ZIP code 2898/2899/6798/6799/7151 can NOT ship via ePacket. Other countries, total price below $30 we will ship your item without tracking number. Otherwise, if you need Registered Mail shipping, please add $2.5(Can choose "Standard Int'l Shipping",we will ship via registered mail). Usually all the items will be shipped via Hong Kong Post Airmail or China Post Airmail. If you need the other express way(EMS/DHL/FedEx/UPS),please contact with us for the correct price. Your order will be dispatched within 2 business days after the full payment is cleared. Airmail Packets' Delivery Time(reference only): USA,Australia,New Zealand,Southeast Asia, East Asia. 7-20 business days. Most European countries (France,Spain,Germany,UK,Sweden, Norway, Denmark,Netherlands,Austria,Portugal, Croatia, Finland, Switzerland, etc.) ,Canada,10-25 business days. Some remote city will take more than 25 business day. Italy,Russia, Brazil, Turkey, Ukraine, India, 14-35 business days, 90% take long time. Eastern Europe,West Asia,Central Asia, 15-30 business days,80% take long time. Africa,Chile,Argentina,Mexico,Other Countries. 15-40 business days,usually long time. Delivery time depends on postal process and other factors(Weather,Vacation,Customs,etc.),it can receive as fast as 7 days,but it can take as long as 4-7 weeks in some cases. If you do not get your item in reference delivery time, please contact us first through ebay message (Please do NOT open any case), we will reply you as soon as possible(within 24 business hours). Return Policy Please contact us before you leave Negative or Neutral Feedback if you are not satisfied with our products,we will resolve it asap. DOA(Dead On Arrival) or Wrong Item will be offered exchange. Refund will be offered if stock is not available Defective goods must be returned within 30 days after receiving it for exchange or refund. Buyer is responsible for return shipping cost in any situations. Contact us Please feel free to contact us from ebay if you have any questions , we will reply you within 48 hours except the weekends and public holidays. Please contact with us before you leaving Negative or Neutral feedback, and please DO NOT open any case, we will try my best to resolve your problems ASAP. Engineered for professional eBay sellers!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country of Manufacture	China
Input voltage	7-35V
Chip	LM2596S
Output voltage	1.25-30V
