Dc-dc Step-up Boost Converter Constant Current Power Supply Module Led Driver

US $39.61

Shenzhen, China
Aug 16th

Open on mobile:
QR code

< class="title"> DC-DC Step-up Boost Converter Constant Current Power Supply Module LED Driver Features: This is a great 1200W DC to DC step-up power supply module for electric equipment, digital products, laptop, etc. Input and output are designed with screw terminals for convenient wire connection and disconnection. High efficiency, the maximum conversion efficiency can be 97% and efficiency is related to input/output voltage, current and voltage difference. There is a big heat sink and cooling fan that would ensure a better heat dissipation. It can also be used as a driver for high power LED lights or voltage regulator for solar panels. Specifications: Type: Non-isolated boost module Input Voltage: DC10V to 60V Max Input Current: 20A (could 25A at 12V-24V when adding cooling fan) Quiescent Current: 15mA(will increase when convert 12V to 20V) Output Voltage: 12V to 83V(continuously adjustable, default 19V) Max Output Current: 18A (related to the input and output voltage difference, the greater voltage difference is, the smaller output current will be. please enhance heat dissipation when current is over 10A) Constant Current Range: 0.5A to 18A(+/-0.3A) Reverse Input Protection: Yes (150A MOS) Lower Voltage Protection: Yes (9V to 50V adjustable) Temperature Control Fan: Yes (Fan starts to work if more than 55) Operating Temperature: -40 to 85(if temperature is too high, please enhance heat dissipation) Frequency: 150KHz Conversion Efficiency: 92% to 97% (Efficiency is related to input/output voltage, current and voltage difference. The smaller difference is, the higher efficiency will be) Input Over-current Protection: Yes (automatically protect when input is more than 25A, and power supply voltage will not increase) Short Circuit Protection: Yes (input 30A fuse) Wiring Method: Terminals (Please use large current copper wire) Size: 130 x 64 x 52mm / 5.12 x 2.52 x 2.04" Voltage Adjustment: Power on module while not connect to load, then adjust "V-ADJ" potentiometer clockwise to increase, counterclockwise to decrease. Due to large output capacitance capacity, response will be slow when adjust high voltage to low voltage. Current Adjustment: Adjust "A-ADJ" potentiometer counterclockwise about 30 circles to minimize the output current before connecting to load. Then adjust "A-ADJ" clockwise to the current value you need.If you use the module for battery charging, connect to output after battery is fully discharged. Low Input Voltage Protection Adjustment: If we set a low input voltage protection for a 12V battery, connect input to a 10V voltage, then adjust RV1(clockwise to increase, counterclockwise to decrease) till UVLO light up. Now the protection voltage is 10V, that is to say, when battery voltage drops to 10V, module won't step up voltage and the output voltage will be same as input voltage. Note: 1, Input voltage must be more than 10V. 2, If a switch power supply is used as input, module should be connect to power and voltage should be adjusted well before connecting to load. When connecting to load, make sure to turn off the power supply first. 3, Power is related to input voltage, and when input voltage increases, power will increase.The maximum input current is 20A.For example, When input voltage is 12V, maximum power is 240W; input 24V, maximum power 480W; input 30V, maximum power 600W. Package Includes: 1 x Module Payment We accept PayPal . We ship item to your PayPal verified address. Payment must be received within 3 days from the date of purchase. Orders will be processed instantly and dispatched in same day normally, so we do NOT accept any Email/Message note after you place orders. Terms Of Sales 1. Our listing price includes the value of goods,packaging cost,and export taxes,not including international duties. 2. duties,taxes,and charges are not included in the item price or shipping fee. 3. The duties are buyers' responsibility.Please check with your country's customs office determine what these additional costs will be prior to your purchase. 4. All disputes arising from the duties will be submitted to eBay for solution. About us Any questions, pls. contact us via ebay message or email us.We will reply your message within 48 hours. If you do not receive our reply within 48 hours, pls. post a message again because sometimes our message system may block some emails. If you are satisfied with our service, pls. kindly leave us a positive feedback and give us the Detailed Seller Rating with all "5 " in very area. Our aim is to provide Level Customer Service, your recognition will encourage us greatly and serve you better. We strive to keep all our customers satisfy. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative feedback without asking for help.Thanks! Contact Us We are happy to answer your questions or resolve any issues you might have with the item you order. Pls contact us through messages. Questions will be answered within 48 hours normally. There is time difference, so please give us a little more time to help you. If you are satisfied with our service, pls. kindly leave us a positive feedback and give us the Detailed Seller Rating with all "5 " in very area. Please don't leave us any neutral or negative feedback or low DSRs without contacting. Communication, then solution. Happy ebay shopping experience needs your kind cooperation! Your feedback is to our success!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Country/Region of Manufacture	China
Input Voltage	DC10V to 60V
MPN	Does Not Apply
UPC	Does Not Apply
ISBN	Does Not Apply
EAN	Does Not Apply
