Dc-dc Step Up Power Apply Module 12v-60v To 12v-80v High-power 600w

US $23.56

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Recommendations For You 1.23V-30V DC-DC Buck Converter Step Down Module LM2596 DC 4.5-30V 0-100A Dual LED Digital Volt meter Ammeter IC2272/2262 4 channel wireless remote control kits MB102 Breadboard Power Supply Module 3.3V/5V LM2577 Adjustable Step-up Power Converter Module DC- DC Visit my eBay Store:ChipWorld Product Name: NEW DC-DC 600W Step Up 12V-60V to 12V-80V Power Apply Module High-Power More Items In Our Store,Click Here! SKU: 2755 Parsts No. : Package: Brand: Quantity: 1 Module parameter: Module name:600W step up constant current module. Module property:Non-isolated step up module(BOOST). Input voltage:two options for input voltage(selection by jumper cap in PCB): 1>.8V-16V(use for 12V storage battery or three series Li-Poly battery).IN this mode,input voltage must not beyond 16V,otherwise module must be damaged. 2>.12V-60V Inout current:16A(max)please use heat sink if input current beyond 10A Static working current:15mA Output voltage:12V-80V(adjustable) Output current:0.1A-12A(please use heat sink if output current beyond 10A) Working temperature:-40°C~+85°C Working frequency:150KHz Transfer efficiency:95%(max) Over current protection:Yes Short circuit protection:Yes Input reverse connect protection:NO Output reverse connect protection:NO PCB size:76x60x56mm Set method of constant current and constant voltage: 1.Set output voltage:if selection 9V-12V,please use jumper cap. 2.Set output current: 1>.adjust CV potentiometer,adjust output voltage. 2>.keep anticlockwise rotate CC potentiometer in 300 circle,set the minimun current Then selection .Then connect to load ,adjust CC potentiometer to set output current that you want. The diameter is 3mm for the holes, can use M3 series screw, triangular thread For more quantity, please contact me.(My skype: ada-yu2013) The Standard shipping we provide is non-regiested mail without a tracking. We provide free shipping with tracking number when your order is over $50. If your oder is below $50 and you need tracking, please contact me. Maybe you request DC-DC Power Supply Buck Converter Step Down Module 4.75V-24V to 0.92V-15V New NEW DC-DC LM2577 Step Up 3.5-30V to 4-30V Booster Power Module NEW DC-DC LM2596 Step Down Power Module 4V-40V to 1.25V~37V Adjustable DC-DC power converter Adjustable 4.5-24V To 0.93-20V Step-Down LED voltmeter Red 1PCS Board MB102 Breadboard Power Supply Module 3.3V/5V For Arduino good $ 3.01 + free shipping $ 4.9 + free shipping $ 7.5 + free shipping $8.23 +free shipping $ 2.66 + free shipping Any problem, please contact us freely 1) We accept PayPal payment ONLY. inkFrog Analytics
