Dc12-36v 500w Brushless Motor Pwm Controller Balanced Bldc Driver Board Zok

US $19.19

Shenzhen, China
Jul 3rd

Open on mobile:
QR code

DC12-36V 500W Brushless Motor PWM Controller Balanced BLDC Driver Board ZOK Description: 100% Brand New & High Quality Specification: Operating voltage: DC 12V-36V Operating Current: <=15A Driver Power: <=500W Speed Voltage: 0.1V-5V Operating Temperature:-40-85°C Humidity: 90%RH Stall protection:Yes Enable Control: Yes Over-current protection: Yes Steering control: Yes Speed control signal: Yes Size: 63*42*17mm(L*W*H); Probe size 3mm,length: fixing hole center distance 57mm; width:fixed hole center distance 36.5mm Power terminal Out: VCC(positive power supply) GND(negative one) MC(motor phases W) MB(motor phases V) MA(motor phase U) Set for the control side: GND control terminal ground VR the governor end 0-5V(corresponding to 10% of motor speed -100%) ZF reversing control(connected to 5V or ground can charge the motor rotation direction) M tachometer pulse output(depending on the number of motor poles corresponding to the number of pulse per revolution of the output number) EL enable control terminal(connected to 5V ot ground running then 5V, grounding the motor stops) 5V 5V control terminal HALL for the hall terminals: 5V Hall power positive Ha Hall signal Hb Hall signal Hc Hall Signal GND Hall negative Wiring: Control terminal for SET: 1. The motor speed control wiring methods: available potentiometer system speed can also be connected to the MCU control, when the potentiometer control wiring, the potentiometer middle pin is connected to VR speed port, potentiometer connected to both ends of 5V and GND terminal voltage more high speed faster. 2. Motor steering control wiring methods: you can switch control can also be connected to the MCU control, to GND in one direction, then in one direction 5V. 3. Pulse speed signal: high and low output . IC can not understand the information with the customer request. Hall signal inputs for hall: Wiring diagram is shown, one corresponding to the HA, HB,HC and on the motor, 5V power supply connected to the motor hal signals positive, GND power supply negative signal to the motor hall. Note: Due to different motor manufacturers to make the hall of hall line order does not necessarily follow the line on the board to match the sequence, need to be adjusted, please parents who pay attention! If the line sequence wrong, does not boot properly, current, or start other phenomena not open, forced to use the drive plate will burn!!! Motor driver board 12-36V DC power input, VCC positive power supply,GND power supply is negative. Please note that the new type and old type of this product will be sent randomly, and make sure you will not mind before ordering. Electrical wiring methods: Brushless DC motor for the three lines, corresponding MA/U,MB/V,MC/W Tips: If you use less than 60W, without additional heat sink , be sure to add more than 60W heatsink fins drive efficiency without lowering the temperature is too high will shine into permanent damage! The size of the heat sink may be a bad environment based work(recommended cooling surface area greater than 200 square centimeters)!When installing the heat sink ,must pay attention to the back of the module 6 MOS pipe insulation, no insulation, it will be adhered to drive plate permanently damaged! Proposes to add insulation films, both sides of the insulating sheet plus thermal grease! Package Includes: 1 x 12-36V 500W Brushless Motor Controler We accept PayPal . We ship item to your PayPal verified address. Payment must be received within 3 days from the date of purchase. All the items will be dispatched within one business day by Airmail after the payment is clear. Most times you will receive your order within 10-30 business days after we transfer your package to the delivery company. We cannot guarantee the delivery timeframe if the post office has any unexpected delays due to holiday, weather, customs, or other conditions. Some countries like Russia, Brazil, or some European countries may take up to 50 days or longer for delivery. We appreciate your patience if you haven't received items in 30 days(Russian customers may need more patience by reason of the local delivery system and/or customs). If you are concerned in any way, please feel free to contact us via ebay message instead of leaving negative/neutral feedback or opening a dispute. We will make every effort to fix any problem(resend or refund any missing item). Customs duty is obligation and liability of citizens in your country, so buyer should be responsible for any tax and custom duty incurred. Generally, the delay or failure delivery is sometimes caused by the policy of different customs. 1. Our listing price includes the value of goods,packaging cost,and export taxes,not including international duties. 2. duties,taxes,and charges are not included in the item price or shipping fee. 3. The duties are buyers' responsibility.Please check with your country's customs office determine what these additional costs will be prior to your purchase. 4. All disputes arising from the duties will be submitted to ebay for solution. 1. Any questions, pls. contact us via ebay message or email us.We will reply your message within 48 hours. If you do not receive our reply within 48 hours, pls. post a message again because sometimes our message system may block some emails. 2. If you are satisfied with our service, pls. kindly leave us a positive feedback and give us the Detailed Seller Rating with all "5 " in very area 3. Our aim is to provide Level Customer Service, your recognition will encourage us greatly and serve you better. We strive to keep all our customers satisfy. We will do our up most to exceed your expectations in customer service, communication and dispatching of your orders. On Jul-03-21 at 03:01:08 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Operating Temperature	-40-85°C
Driver Power	<=500W
Operating voltage	DC 12V-36V
Humidity	90%RH
Size	634217mm(LWH)
MPN	Does Not Apply
Speed Voltage	0.1V-5V
Operating Current	<=15A
UPC	Does Not Apply
ISBN	Does Not Apply
EAN	Does Not Apply
