Dc12v 4ch Digital Remote Control Switch 4 Outputs Learning Code 10a Relay

US $16.99

???, ???, China
Jan 29th

Open on mobile:
QR code

DC12V 4CH Digital Remote Control Switch 4 Outputs Learning Code 10A Relay Item specifics is_customized:YesOperating Temperature:-40°C-+60°CBrand Name:aokeMax. Voltage:DC12VMax. Current:10AModel Number:AK-RK04S-12Place of Origin:China (Mainland)Operating Voltage:DC12VOperating Temperature:-40°C-+60°CWorking frequency:315MHZ/433MHzWorking way:jog/interlock/self-lockCoding type:Learning codeCH :4CHPCB Size:70*50*18mm Product Description RF DC12V 4 CH Learning code remote control switch Feature: · Control Lights, Motors, Fans, electrically operated Doors/Locks/Windows/Blinds/Cars or Other Appliances with AC220V,AC85V-260V OR DC12V.. · You can turn on/off the receiver with transmitter (remote control) from any place within a reliable distance; the wireless RF signal can pass through walls, floors and doors. · This switch can learn different coding remote controls (such as 2262,1527 ect.) · One/several transmitters can control one/several receivers simultaneously. · The wireless receiving controller, with high confidentiality, stable performance, low power consumption characteristic, jump line or dial the code switch coding. About Receiver: · Model No.: AK-RK04S-12 · Channel: 4 CH Radio Frequency:315MHZ/433MHZ Operating Voltage: DC12V Operating Type:Jog /Momentary/Non-Latched(Press and hold->On,Release->Off) Interlock /Latched(Press -> On; Press other button -> Off) Self-lock/Toggle(Press->On,Press again->Off) · Coding Type: learning code · Maximum Working Current: 10A · Output Mode: Without voltage output(also called Contact output) · Step-down approach: resistance-capacitance(RC) About Transmitter : Module No: AK-TF04 Buttons : 4 buttons Battery : 12V 23A battery *1 pcs Remote size: 50*33*10mm Distance : 10-50M About Learning and clearing Method: Learning:· Press the learning key, it means the controller putting in the learning state when the indicator goes out, then please press any buttons of the remote control to transmit signals, the indicator will flash , then normally on, which means successfully studied. Clearning: Hold press learning button about 8 seconds,,indicator from on to off,then press remote ,receiver did not work ,it means clearning code successful. Here is 4CH receiver with 4 buttons remote ,default working way is Momentary (jog) ,frequency random shipping ,if you have requirements,pls leave a messege to me . Package Included: 1 pcs receiver (with a plastic case) 2 pcs remote (with battery) Shipping and Handling We ship worldwide by international air mail from Hongkong Airway Postal and China Airway postal. Email us before payment to arrange UPS Speed post for 2 to 7 days delivery. We will offer a free Registered Number for the flat rate shipping service once the total value of your order is over $25. Otherwise, you have to pay extra $2.5 as the registered cost if you want to apply register service. We reserve the rights not to ship to any zero/negative feedback rating buyers. Items will be shipped out in most cases within 48 hours of payment being received. (Excluding Weekends and Public Holidays) Due to security reason, we reserve the right not to send items to unconfirmed Paypal address. Delivery Time Country Approx. Delivery time United States 7-21 working days Canada / United Kingdom / Australia 15-30 working days Italy / France / Spain / Germany/ Eastern Europe/Brazil / South America 30-40 working days
