Dds Function Signal Generator Counter Signal Source Frequency Pulse Generator

US $70.08

Shen Zhen, China
Jul 27th

Open on mobile:
QR code

DDS Function Signal Generator Counter Signal Source Frequency Pulse Generator DDS Function Signal Generator Counter Signal Source Frequency Meter Pulse Generator Synthesizer QLS2800S 2MHz / 5MHz Description: 100% brand new,high quality The internal circuit adopts surface mount technology, which greatly improves the anti-interference and service life of the instrument. The display interface adopts a 2.4-inch TFT liquid crystal display with 320*240 high resolution, which can display all the parameters of the channel and prompt the current button functions, effectively utilize the button resources, and avoid frequent user button operations, greatly enhancing the display interface. Operability. It is an ideal test and measurement equipment for electronic engineers, electronic laboratories, production lines and teaching and research. Features: 1.Direct digital synthesis (DDS) technology, FPGA design, ultra-low power consumption; 2.a single DC5V power adapter power supply, easy to carry; 3.using 2.4-inch TFT true color LCD screen, with variable function buttons and rotary encoder, greatly enhance the ease of use of the machine; 4.Basic function waveforms such as sine wave, triangle wave, square wave, sawtooth wave, and pulse wave with adjustable duty cycle; 5.the output signal frequency can be as small as 0.01 Hz; 6.There are 10 sets of parameter storage bits of M0~M9, and the data of M0 is automatically called up when booting; 7.The waveform frequency resolution is at least 0.01 Hz, and the amplitude resolution is at least 10 mV; 8.It has two trigger modes: manual trigger and external trigger. It can make the machine output any pulse train from 1 to 999999. 9.the pulse wave duty cycle adjustment is accurate to 0.5%; 11.Frequency scanning with an end point; 12.with frequency measurement, counting function; 13.All parameters can be calibrated by internal procedures; 14.powerful communication functions, making open communication protocol, making secondary development very simple; 15.After connecting with the PC, the PC can be used to control the instrument; 16.The operation interface can be switched between Chinese and English, and the scope and scope are wider; Function display: (1) Wave output function: output frequency 100K, peak-to-peak value 10V, sine wave signal with zero offset. (2) Wave output function: square wave signal with output frequency 100K, peak-to-peak value 10V, offset to zero (3) Wave output function: output frequency 100K, peak-to-peak value 10V, triangular wave signal with zero offset. (4) Wave output function: output sawtooth angular wave signal with output frequency 100K, peak-to-peak value 10V, and offset to zero. (5) Wave output function: output frequency 100K, peak-to-peak value 10V, offset to zero sawtooth angular wave signal. (6) Waveform output function: square wave angle wave signal with output frequency 100K, peak-to-peak value 10V, offset of +100%, and duty cycle of 10%. (7) Waveform output function: square wave angle wave signal with output frequency 100K, peak-to-peak value 10V, offset of -100%, and duty ratio of 90%. (8) Wave output function: output frequency 3M, peak-to-peak value 10V, sine wave signal with zero offset. (9) Wave output function: output frequency 3M, peak-to-peak value 10mV, sine wave signal with zero offset. (10) External burst function: The oscilloscope comes with a 1K square wave signal, and the external trigger function outputs three cycles of a sinusoidal waveform with a frequency of 100K. Specifications: Item Type: Signal Generator Material: Plastic Patterns2Mhz/5Mhz Package Size: approx.25x28x12cm/9.84x11.02x4.72in Color:White Quantity: 1 Pc Note: Transition: 1cm=10mm=0.39inch. Please allow 0-1cm error due to manual measurement. pls make sure you do not mind before you bid. Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you! Package Includes: 1 * QLS2802S 1 * Q9 clip line; 1 * BNC-BNC line; 1 * Port USB cable; 1 * DC5V power adapter;

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
MPN	Does Not Apply
