Dds Function Waveform Signal Generator 0.1hz To 3mhz Ac 220v Ca1645-3

US $114.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Note: This item supports 220V power supply only, not for 110V. This series uses the latest Direct Digital synthesis (DDS) technology to generate stable, high resolution output frequency. The DDS technology solves several problems encountered in traditional function generators, as follows. Temperature change inside the generator greatly affects the components characteristics which lead to output frequency change. The results are poor accuracy and stability ect. The meter is the ideal equipment of electronic engineers, laboratories, production lines and the teaching and research. Main Features: High resolution using DDS technology High frequency accuracy : ±20ppm Low distortion: <0.6% High resolution: 100 mHz Digital user interface with 6-digit LED display Various output waveforms: Sine, Square and Triangle TTL/CMOS output Amplitude control -40dB attenuation Duty control Variable DC level control Output On/Off control Voltage display Frequency output TTL/CMOS output Specifications Main Output Waveforms Sine , Square , and Triangle Amplitude 20Vp-p(no Load) Impedance 50?±10% Attenuation 0dB, 40dB DC offset ±10V (no Load) Duty cycle range 20% - 80% (Square wave) Display 6 digits LED Frequency Sine wave 0.1Hz - 3MHz Square wave 0.1Hz - 2MHz (Valid Range) Triangle wave 0.1Hz ~-1MHz (Valid Range) Resolution 100mHz Frequency stability ±1x10-6 Frequency error ±5x10-6 Square Wave Distortion <0.6% (Foundation frequency: 1kHz) Triangle Wave Linearity >=98%,100mHz~100kHz;>=95%,100kHz~1MHz; Square Wave Rising & falling time <30ns TTL/CMOS Amplitude >=3 Vp-p Fan Out 20TTL Load CMOS level 3.5~13.5 Vp-p Others Supply voltage AC 220V ±10%,50Hz±5% Line voltage setting is factory installed Wide 265(W)x110(H)x300(D) Weigh About 2.5kg Accessories: Power cord, probe. Note: we'll ship this item via express mail service to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Malta, Norway, Sweden, Swiss, Spain, Italy, UK, Japan, Korea,Thailand, Malaysia, Indonesia, Philippine, Singapore. Clients from other countries pls contact with us in advance to confirm the different shipping charges before you bid.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	CA1645-3
Country/Region of Manufacture	China
MPN	CA1645-3
Country of Manufacture	China
